Norton Commando 961 Café Racer MIII "Mick Grant Special" Limited Edition (2016) technical specifications

Norton Commando 961 Café Racer MIII "Mick Grant Special" Limited Edition technical specifications

Norton Commando 961 Café Racer MIII "Mick Grant Special" Limited Edition is produced in 2016. Engine is Four stroke, parallel twin with push-rod valve actuation, 3 bearing crank balancer shaft, 2 valves per cylinder, displacement 961 cc / 58.6 cu in , produces power 59.7 kW / 80 hp @ 6500 rpm and 90 Nm / 9.2 kgf-m / 65 ft-lb @ 5200 rpm. Norton Commando 961 Café Racer MIII "Mick Grant Special" Limited Edition weighs 188 kg / 414 lbs. Norton Commando 961 Café Racer MIII "Mick Grant Special" Limited Edition has 4 photos.

Technical specifications

+ Add to 'Compare list'
Model: Commando 961 Café Racer MIII "Mick Grant Special" Limited Edition
Years: 2016
Engine: Four stroke, parallel twin with push-rod valve actuation, 3 bearing crank balancer shaft, 2 valves per cylinder
Capacity: 961 cc / 58.6 cu in
Bore x Stroke: 88 x 79 mm
Compression Ratio: 10.1:1
Cooling System: Air cooled
Lubrication: Dry sump
Induction: Fuel injected
Ignition: Crank fired electronic
Starting: Electric
Max Power: 59.7 kW / 80 hp @ 6500 rpm
Max Torque: 90 Nm / 9.2 kgf-m / 65 ft-lb @ 5200 rpm
Clutch: Wet multi-plate with hydraulic lifter
Transmission: 5 Speed, constant mesh
Final Drive: Chain, 525 "O" ring
Frame: Tubular steel with integral oil tank
Rake: 24.5°
Trail: 99 mm / 3.9 in
Front Suspension: Ø43 mm Öhlins RSU, adjustable preload, compression, and rebound damping.
Front Wheel Travel: 115 mm / 4.53 in
Rear Suspension: Öhlins reservoir-style twin shocks, adjustable ride height, preload, compression, and rebound damping.
Rear Wheel Travel: 100 mm / 3.94 in
Front Brakes: Brembo 2 x Ø320 mm semi-floating carbon stainless steel discs, 4 piston "Gold Line" axial calipers
Rear Brakes: Brembo single Ø220 mm disc, 2 piston "Gold Line"caliper
Front Wheel: 3.50 x 17", BST carbon fibre
Rear Wheel: 5.00 x 17", BST carbon fibre
Front Tyre: 120/70 -17
Rear Tyre: 180/55 -17
Wheelbase: 1420 mm / 55.9 in
Dry Weight: 188 kg / 414 lbs
Seat Height: 813 mm / 32 in
Fuel Capacity: 17 Litres / 4.5 US gal
