1970 Norton Commando 750 Roadster technical specifications
Technical specifications
|
|
|---|---|
| Model: | Commando 750 Roadster |
| Years: | 1970-71 |
| Engine: | Four stroke, parallel twin cylinder, push rod 2 valves per cylinder. |
| Capacity: | 745 cc / 45.5 cu in |
| Bore x Stroke: | 73 x 89 mm |
| Compression Ratio: | 9.0:1 |
| Cooling System: | Air cooled |
| Starting: | Kick |
| Max Power: | 58 hp / 43 kW @ 6800 rpm |
| Transmission: | 4 Speed |
| Final Drive: | Chain |
| Front Suspension: | Telescopic forks |
| Rear Suspension: | Dual shocks |
| Front Brakes: | Single 203 mm drum |
| Rear Brakes: | Single 178 mm drum |
| Front Tyre: | 3.25-19 |
| Rear Tyre: | 4.00-18 |
| Dimensions: | Length 2220 mm / 87.5 in Width 660 mm / 26 in |
| Wheelbase: | 1441 mm / 56.75 in |
| Seat Height: | 863.6 mm / 34 in |
| Dry Weight: | 195 kg / 430 lbs |
| Fuel Capacity: | 10 Litres / 2.6 US gal |
| Standing ¼ Mile: | 12.92 sec |
