MV Agusta Stradale 800 (2017) technical specifications

MV Agusta Stradale 800 technical specifications

MV Agusta Stradale 800 is produced in 2017. Engine is Four stroke, transverse three cylinder. DOHC, 4 Valve per cylinder,, displacement 798 cc / 48.7 cu-in , produces power 84.5 kW / 115 hp @ 11000 rpm and 78.5 Nm / 8.0 kgm @ 9000 rpm.. MV Agusta Stradale 800 weighs 181 kg / 399 lbs. MV Agusta Stradale 800 has 5 photos.

Technical specifications

+ Add to 'Compare list'
Model: Stradale 800
Years: 2017
Engine: Four stroke, transverse three cylinder. DOHC, 4 Valve per cylinder,
Capacity: 798 cc / 48.7 cu-in
Bore x Stroke: 79 x 54.3 mm
Cooling System: Liquid Cooled
Compression Ratio: 13.3:1
Engine Management System: Integrated ignition - injection system MVICS (Motor & Vehicle Integrated Control System) with three injectors. Engine control unit Eldor NEMO EM2.0, throttle body full drive by wire Mikuni Ø 47.0 pencil-coil ELDOR with ion-sensing technology, control of detonation and misfire. Torque control with four maps, Traction Control with eight levels of intervention Electronic quick shift MV EAS 2.0 (Electro
Ignition: Multipoint electronic injection
Starting: Electric
Battery: PERFDRfTIFinCE
Alternator: 350 Wat 5000 r.p.m. 12V-8.6Ah
Max Power: 84.5 kW / 115 hp @ 11000 rpm
Max Torque: 78.5 Nm / 8.0 kgm @ 9000 rpm.
Clutch: Wet, multi-disc with mechanical drive Cassette style
Transmission: 6 Speed
Final Drive: Chain
Gear Ratio: 1st 13/37 2nd 16/34 3rd 18/32 4th 19/30 5th 21/30 6th 22/29
Final Drive Ratio: 16/41
Frame: ALS Steel tubular trellis (MAG welded) Rear swing arm pivot plates material Aluminium alloy
Front Suspension: 43mm Marzocchi “UPSIDE DOWN” telescopic hydraulic fork with rebound-compression damping and spring preload external and separate adjustment
Front Wheel Travel: 150 mm / 5.6 in
Rear Suspension: Progressive Sachs, single shock absorber with rebound and compression damping and spring preload adjustment Single sided swing arm material Aluminium alloy
Rear Wheel Travel: 150 mm / 5.6 in
Front Brakes: 2x 320mm floating discs 4 piston calipers
Rear Brakes: Single 220mm disc 2 piston caliper
ABS System: Bosch 9 Plus with RLM (Rear wheel Lift-up Mitigation)
Rim Front: Material/size Aluminium alloy 3.50 ” x 17 ”
Rim Rear: Material/size Aluminium alloy 5.50 ” x 17 ”
Front Tyre: 120/70 - ZR 17 M/C (58 W)
Rear Tyre: 180/55 - ZR 17 M/C (73 W)
Trail: 109 mm / 4.25 in
Dimensions: Length 2130 mm / 83.86 in Width 890 mm / 35.04 in
Wheelbase: 1460 mm / 57.4 in
Ground Clarence: 125 mm / 4.9 in
Seat Height: 870 mm / 34.23 in
Dry Weight: 181 kg / 399 lbs
Fuel Capacity: 16 Litres / 4.28 us gal
