MV Agusta F3 800 RC Limited Edition (2017) technical specifications

MV Agusta F3 800 RC Limited Edition technical specifications

MV Agusta F3 800 RC Limited Edition is produced in 2017. Engine is Four stroke, transverse three cylinder. DOHC, 4 Valve per cylinder, displacement 798 cc / 48.6 cu-in , produces power 108.8 kW / 148 hp @ 13000 rpm and 88 Nm / 8.97 kg-m @ 10600 rpm. MV Agusta F3 800 RC Limited Edition weighs 173 Kg / 381.4 US lbs. MV Agusta F3 800 RC Limited Edition has 6 photos.

Technical specifications

+ Add to 'Compare list'
Model: F3 800 RC Limited Edition
Years: 2017
Engine: Four stroke, transverse three cylinder. DOHC, 4 Valve per cylinder
Capacity: 798 cc / 48.6 cu-in
Bore x Stroke: 79 x 54.3 mm
Compression Ratio: 13.3;1
Cooling System: Cooling with separated liquid and oil radiators
Engine management system: Integrated ignition - injection system MVICS (Motor & Vehicle Integrated Control System) with six injectors Engine control unit Eldor EM2.0, throttle body full drive by wire Mikuni, pencil-coil with ion-sensing technology, control of detonation and misfire Torque control with four maps,
Traction: Control with eight levels of intervention Electronic quick shift MV EAS (Electronically Assisted Shift)
Ignition: Multipoint electronic injection
Starting: Electric
Alternator: 350 W at 5000 r.p.m.
Battery: 12 V - 8.6 Ah
Max Power: 108.8 kW / 148 hp @ 13000 rpm
Max Torque: 88 Nm / 8.97 kg-m @ 10600 rpm
Clutch: Wet, multi-disc with mechanical drive Cassette style
Transmission: 6 Speed
Final Drive: Chain
Gear Ratio: 1st 13/37 2nd 16/34 3rd 18/32 4th 19/30 5dth 21/30 6th 22/29
Final Drive Ratio 1: 17/4
Frame: Type ALS Steel tubular trellis Rear swing arm pivot plates material Aluminium alloy
Front Suspension: 43mm Marzocchi "UPSIDE DOWN" telescopic hydraulic fork with rebound-compression damping and spring preload external, and separate adjustment
Front Wheel Travel: 125 mm / 4.6 in
Rear Suspension: Progressive Sachs, single shock absorber with rebound and compression damping and spring preload adjustment Single sided swing arm material Aluminium alloy
Rear Wheel Travel: 123 mm / 4.8 in
Front Brakes: 2x 320mm floating discs 4 piston calipers
Rear Brakes: Single 220mm disc 2 piston caliper
Rim Front: Aluminium alloy 3.50 " x 17 '
Rim Rear: Aluminium alloy 5.50 " x 17 '
Front Tyre: 120/65 ZR17
Rear Tyre: 180/55 ZR17
Trail: 99 mm / 3.89 in
Dimensions: Length 2060 mm / 81.01 in Width 725 mm / 28.5 in
Wheelbase: 1380 mm / 54.33 in
Seat Height: 805 mm / 31.6 in
Ground Clarence: 125 mm / 4.2 in
Dry Weight: 173 Kg / 381.4 US lbs
Fuel Capacity: 16.6 Litres / 4.3 US gal
Reserve: 5 Litres / 1.3 US gal
