MV Agusta F3 675 RC Limited Edition (2015) technical specifications

MV Agusta F3 675 RC Limited Edition technical specifications

MV Agusta F3 675 RC Limited Edition is produced in 2015. Engine is Four stroke, transverse three cylinder. DOHC, 4 Valve per cylinder,, displacement 675 cc / 41.4 cu-in , produces power 94.2 kW / 126 hp @ 14400 rpm - Lim. 15000 rpm. and 71 Nm / 7.24 kgm @ 10600 rpm.. MV Agusta F3 675 RC Limited Edition top speed is 258.5 km/h / 160.3 mph. MV Agusta F3 675 RC Limited Edition weighs 173 kg / 381.4 lbs. MV Agusta F3 675 RC Limited Edition has 5 photos.

Technical specifications

+ Add to 'Compare list'
Model: F3 675 RC Limited Edition
Years: 2015
Engine: Four stroke, transverse three cylinder. DOHC, 4 Valve per cylinder,
Capacity: 675 cc / 41.4 cu-in
Bore x Stroke: 79 x 45.9 mm
Compression Ratio: 13.0:1
Cooling System: Liquid Cooled
Induction: Integrated ignition - injection system with six injectors Engine control unit Eldor EM2.0, throttle body full drive by wire Mikuni, pencil-coil with ion-sensing technology, control of detonation and misfire Torque control with four maps, Traction Control with eight levels of intervention
Ignition: Digital CDI
Alternator: 350 W at 5000 r.p.m.
Battery: 12 V - 8.6 Ah
Starting: Electric
Max Power: 94.2 kW / 126 hp @ 14400 rpm - Lim. 15000 rpm.
Max Torque: 71 Nm / 7.24 kgm @ 10600 rpm.
Clutch: Wet, multiple discs, cable operated
Transmission: 6 Speed
Final Drive: Chain
Gear Ratio: 1st : 1/14.493 2nd: 1/10.821 3rd: 1/9.053 4th: 1/8.040 5th: 1/7.274 6th: 1/6.712
Final Drive Ratio: 16/43
Frame: ALS Steel tubular trellis, Rear swing arm pivot plates: material Aluminium alloy
Front Suspension: 43mm “UPSIDE - telescopic hydraulic fork with rebound-compression damping and spring preload external and separate adjustment,
Front Wheel Travel: 125 mm / 4.92 in
Rear Suspension: Progressive, single shock absorber with rebound and compression (High speed/ Low speed) damping and spring preload adjustment,
Rear Wheel Travel: 123 mm / 4.84 in
Front Brakes: 2x 320mm Double floating discs, 4 pistons calipers
Rear Brakes: Single 220mm disc, single piston calipers
Rim Front: Material/size Aluminium alloy 3.50 ” x 17 ”
Rim Rear: Material/size Aluminium alloy 5.50 ” x 17 ”
Front Tyre: 120/70-ZR17
Rear Tyre: 190/55-ZR17
Trail: 99 mm / 3.89 in.
Rake: 23.6°
Dimensions: Length 2060 mm./ 81.01 in Width 725 mm / 28.54 in
Wheelbase: 1380 mm / 54.33 in.
Seat Height: 805 mm / 31.6 in
Ground Clearance: 125 mm / 4.92 in.
Dry Weight: 173 kg / 381.4 lbs
Fuel Capacity: 16 Litres / 4.2 gal
Consumption Average: 17.9 km/lit
Standing ¼ Mile: 11.1 sec
Top Speed: 258.5 km/h / 160.3 mph
