MV Agusta Dragster 800 Rosso (2020) technical specifications

MV Agusta Dragster 800 Rosso is produced in 2020. Engine is Four stroke, transverse three cylinder. DOHC, 4 Valve per cylinder, displacement 798 cc / 48.69 cu-in , produces power 81 kW / 110 hp @ 11500 rpm and 83 Nm / 61.2 lb-ft @ 7600 ron. MV Agusta Dragster 800 Rosso weighs 168 Kg / 370.38 lbs. MV Agusta Dragster 800 Rosso has 4 photos.

Technical specifications

+ Add to 'Compare list'

Model:	Dragster 800 Rosso
Years:	2020
Engine:	Four stroke, transverse three cylinder. DOHC, 4 Valve per cylinder
Capacity:	798 cc / 48.69 cu-in
Bore x Stroke:	79 x 54.3 mm
Cooling System:	Cooling with separeted liquid and oil radiators
Compression Ratio:	12.3:1
Engine Management System:	Integrated ignition – injection system MVICS (Motor & Vehicle Integrated Control System) with three injectors. Engine control unit Eldor EM2.0, throttle body full drive by wire Mikuni, pencil-coil. Torque control with four maps, Traction Control with eight levels of intervention.
Environmental Standard:	Euro 4
Ignition:	Multipoint electronic injection
Starting:	Electric
Max Power:	81 kW / 110 hp @ 11500 rpm
Max Torque:	83 Nm / 61.2 lb-ft @ 7600 ron
Electronic Quick-shift:	MV EAS 2.0 (Electronically Assisted Shift up & down)
Clutch:	Hydraulically actuated Wet-clutch, multi-disc with back torque limiting device
Transmission:	6 Speed constant mesh
Final Drive:	Chain
Gear Ratio:	1st: 13/37 2nd: 16/35 3rd: 18/32 4th: 20/30 5th: 22/29 6th: 21/25
Primary Drive:	19/36
Final Drive Ratio:	16/41
Frame:	ALS Steel tubular trellis, aluminium alloy rear swing arm pivot plates
Front Suspension:	43mm Type Marzocchi USD telescopic hydraulic fork in DLC treated aluminium, with anodized fork legs and having rebound-compression damping and spring preload external and separate adjustment
Front Wheel Travel:	125 mm / 4.92 in
Rear Suspension:	Progressive Sachs, single shock absorber with rebound and compression damping and spring preload adjustment, Aluminium alloy single sided swing arm
Rear Wheel Travel:	125 mm / 4.92 in
Front Brakes:	2x 320mm floating discs, 4 piston Brembo calipers
Rear Brakes:	Single 220mm disc 2 piston Brembo caliper
ABS:	Bosh 9 Plus with rear wheel lift-up mitigation (RLM)
Rim Front:	Material/size With aluminium alloy spokes 3.50 x 17 in
Rim Rear:	Material/size With aluminium alloy spokes 6.00 x 17 in
Front Tyre:	120/70- ZR 17 M/C (58 W)
Rear Tyre:	200/50- ZR 17 M/C (75 W)
Trail:	103.5 mm / 4.07 in
Dimensions:	Length: 2035 mm / 80.1 in Width: 935 mm / 36.8 in
Wheelbase:	1400 mm / 55.1 in
Seat Height:	845 mm / 33.3 in
Ground Clarence:	135 mm / 5.3 in
Dry Weight:	168 Kg / 370.38 lbs
Fuel Capacity:	16.5 Litres / US 4.36 gal
Reserve:	5 Litres / 1.3 US gal
