MV Agusta Brutale 1090R / ABS (2013) technical specifications

MV Agusta Brutale 1090R / ABS is produced in 2013. Engine is Four stroke, transverse four cylinder. DOHC, 4 radial valves per cylinder, displacement 1078 cc / 65.7 cu-in , produces power 106 kW / 144.2 hp @ 10600 rpm and 115 Nm / 11.5 kgf-m @ 8000 rpm. MV Agusta Brutale 1090R / ABS top speed is 245.8 km/h / 152.7 mph. MV Agusta Brutale 1090R / ABS weighs 190 Kg / 418.9 lbs. MV Agusta Brutale 1090R / ABS has 5 photos.

Technical specifications

+ Add to 'Compare list'

Model:	Brutale 1090R / ABS
Years:	2013
Engine:	Four stroke, transverse four cylinder. DOHC, 4 radial valves per cylinder
Capacity:	1078 cc / 65.7 cu-in
Bore x Stroke:	79 x 55 mm
Cooling System:	Liquid cooled
Compression Ratio:	13.0;1
Induction:	"Weber Marelli" 5SM ignition - injection integrated system; induction discharge electronic ignition; sequential timed "Multipoint" electronic injection
Alternator:	350 W at 5000 r.p.m
Battery:	12 V - 8.6 Ah
Starting:	Electric
Max Power:	106 kW / 144.2 hp @ 10600 rpm
Max Torque:	115 Nm / 11.5 kgf-m @ 8000 rpm
Clutch:	Wet, multi - disc with mechanical anti-surging device
Transmission:	6 Speed
Final Drive:	Chain
Gear Ratio:	1st 13/38 109.7 km/h (68.1 mph) @ 11650 rpm. 2nd 16/34 150.8 km/h (93.6 mph) @ 11650 rpm 3rd 18/32 180.3 km/h (111.9 mph) @ 11650 rpm 4th 20/30 213.7 km/h (132.7 mph) @ 11650 rpm 5th 22/29 243.2 km/h (151.0 mph) @ 11650 rpm 6th 19/23 265.0 km/h (164.5 mph) @ 11650 rpm
Frame:	Type AIS Steel tubular trellis (MAG welded) Rear swing arm pivot plates: material Aluminium alloy
Front Suspension:	Type "UPSIDE - DOWN" telescopic hydraulic fork with external and separated adjustment of rebound and compression damping and of spring preload Rod dia. 50 mm
Front Wheel Travel:	120 mm / 4.7 in
Rear Suspension:	Type Progressive, single shock absorber with rebound damping and spring preload adjustment Single sided swing arm: material Aluminium alloy
Rear Wheel Travel:	120 mm / 4.7 in
Front Brakes:	2x 310mm discs 4 piston caliper
Rear Brakes:	Single 210mm disc 4 piston caliper
Front Wheel:	Aluminium alloy 3.50" x 17"
Rear Wheel:	Aluminium alloy 6.00"x 17
Front Tyre:	120/70 ZR 17
Rear Tyre:	190/55 ZR 17
Trail:	103,5 mm / 4.0 in
Dimensions:	Length 2045 mm / 80.51 in Width 775 mm / 30.5 in
Wheelbase:	1438 mm / 56.6 in
Seat Height:	825 mm / 32.4 in
Ground Clearance:	140 mm / 5.5 in
Dry Weight:	190 Kg / 418.9 lbs
Fuel Capacity:	23 Litres / 6.0 US gal
Consumption Average:	17.9 km/lit
Standing ¼ Mile:	11.4 sec
Top Speed:	245.8 km/h / 152.7 mph
