MV Agusta Brutale 1090 (2013) technical specifications

MV Agusta Brutale 1090 technical specifications

MV Agusta Brutale 1090 is produced in 2013. Engine is Four stroke, transverse four cylinder. DOHC, 4 radial valves per cylinder, displacement 1078 cc / 65.7 cu-in , produces power 106 kW / 144.2 hp @ 10600 rpm and 115 Nm / 11.5 kgf-m @ 8000 rpm. MV Agusta Brutale 1090 weighs 183 kg / 403.5 lbs. MV Agusta Brutale 1090 has 4 photos.

Technical specifications

+ Add to 'Compare list'
Model: Brutale 1090
Years: 2013
Engine: Four stroke, transverse four cylinder. DOHC, 4 radial valves per cylinder
Capacity: 1078 cc / 65.7 cu-in
Bore x Stroke: 79 x 55 mm
Cooling System: Liquid cooled
Compression Ratio: 13.0;1
Induction: Engine management system Magneti Marelli IAW 5SM ignition - injection integrated system with Mikuni throttle body; induction discharge electronic ignition; sequential timed "Multipoint" electronic injection
Alternator: 350 W at 5000 r.p.m
Battery: 12 V - 8.6 Ah
Starting: Electric
Max Power: 106 kW / 144.2 hp @ 10600 rpm
Max Torque: 115 Nm / 11.5 kgf-m @ 8000 rpm
Clutch: Wet, multi-disc
Transmission: 6 Speed
Final Drive: Chain
Gear Ratio: 1st 13/38 109.7 km/h (68.1 mph) @ 11650 rpm. 2nd 16/34 150.8 km/h (93.6 mph) @ 11650 rpm 3rd 18/32 180.3 km/h (111.9 mph) @ 11650 rpm 4th 20/30 213.7 km/h (132.7 mph) @ 11650 rpm 5th 22/29 243.2 km/h (151.0 mph) @ 11650 rpm 6th 19/23 265.0 km/h (164.5 mph) @ 11650 rpm
Frame: Type AIS Steel tubular trellis (MAG welded) Rear swing arm pivot plates: material Aluminium alloy
Front Suspension: 50mm Marzocchi "UPSIDE - DOWN" telescopic hydraulic fork with external and separated adjustment of rebound and compression damping and of spring preload Travel on leg axis
Front Wheel Travel: 120 mm / 4.7 in
Rear Suspension: Type Progressive, single shock absorber with rebound damping and spring preload adjustment Single sided swing arm: material Aluminium alloy
Rear Wheel Travel: 120 mm / 4.7 in
Front Brakes: 2x 310mm discs 4 piston caliper
Rear Brakes: Single 210mm disc 4 piston caliper
Front Tyre: 120/70 ZR 17
Rear Tyre: 190/55 ZR 17
Dimensions: Length 2100 mm / 82.6 in Width 775 mm / 30.5 in
Wheelbase: 1438 mm / 56.6 in
Seat Height: 825 mm / 32.48 in
Dry-Weight: 183 kg / 403.5 lbs
Fuel Capacity: 23 Litres / 6.0 U.S. gal
