Technical specifications
|
| Model: |
V 50C |
| Years: |
1982-86 |
|
Engine:
|
Four stroke, V twin, longitudinally mounted, OHV, 2 valve per cylinder.
|
|
Capacity:
|
490 cc / 29.9 cu-in
|
|
Bore x Stroke:
|
74 x 57 mm
|
|
Cooling System:
|
Air cooled
|
|
Compression Ratio:
|
10.4:1
|
|
Induction:
|
2x 28mm Dell'Orto PHBH carburetors
|
|
Ignition:
|
Battery powered inductive
|
|
Starting:
|
Electric
|
|
Max Power:
|
48 hp / 35.7 kW @ 7500 rpm
|
|
Max Torque:
|
NA
|
|
Transmission:
|
5 Speed
|
|
Final Drive:
|
Shaft
|
|
Frame:
|
Duplex spine type
|
|
Front Suspension:
|
Telehydraulic gas forks
|
|
Front Brakes:
|
2x 260mm discs
|
|
Rear Brakes:
|
Single 235mm disc
|
|
Front Tyre:
|
100/90 H18
|
|
Rear Tyre:
|
130/90 H16
|
|
Dry Weight:
|
165 kg / 363.7 lbs
|
|
Fuel Capacity:
|
15 Litres / 3.9 US gal
|
