Moto Guzzi NTX 350 (1987-) technical specifications
Moto Guzzi NTX 350 is produced in 1987-. Engine is Four stroke, 90° V twin, longitudinally mounted, OHV, 2 valve per cylinder., displacement 346.2 cc / 21.1 cu-in , produces power 35 hp / 26 kW @ 8100 rpm and 27.3 Nm / 20.2 lb-ft @ 6500 rpm. Moto Guzzi NTX 350 top speed is 139.7 km/h. Moto Guzzi NTX 350 weighs 165 kg / 363.7 lbs. Moto Guzzi NTX 350 has 1 photos.
Technical specifications
+ Add to 'Compare list'| Model: | NTX 350 |
| Years: | 1987- |
| Engine: | Four stroke, 90° V twin, longitudinally mounted, OHV, 2 valve per cylinder. |
| Capacity: | 346.2 cc / 21.1 cu-in |
| Bore x Stroke: | 66 x 50.6 mm |
| Cooling System: | Air cooled |
| Compression Ratio: | 10.5:1 |
| Induction: | 2x Dell'Orto PHBH 28 carburetors |
| Ignition: | Electronic |
| Starting: | Electric |
| Max Power: | 35 hp / 26 kW @ 8100 rpm |
| Max Power Rear Tyre: | 30 hp / 22.3 kW @ 7800 rpm |
| Max Torque: | 27.3 Nm / 20.2 lb-ft @ 6500 rpm |
| Transmission: | 5 Speed |
| Final Drive: | Chain |
| Front Suspension: | Hydraulic telescopic forks |
| Rear Suspension: | Twin shocks |
| Front Brakes: | Single 260mm disc 2 piston caliper |
| Rear Brakes: | Single 260mm disc 1 piston caliper |
| Front Tyre: | 3.00_21 |
| Rear Tyre: | 4.00 _18 |
| Dry Weight: | 165 kg / 363.7 lbs |
| Wet Weight: | 182 kg / 401 lbs |
| Fuel Capacity: | 32 Litres / 8.4 US gal |
| Consumption Average: | 16.7 km/lit |
| Braking 60 - 0 / 100 - 0: | 16.8 m /46.6 m |
| Standing ¼ Mile: | 16.9 sec / 117.9 km/h |
| Top Speed: | 139.7 km/h |
