Technical specifications
|
| Model: |
Nevada 350 |
| Years: |
1994-97 |
|
Engine:
|
Four stroke, 90°V twin, longitudinally mounted, OHV, 2 valve per cylinder.
|
|
Capacity:
|
346 cc / 21.1 cu-in
|
|
Bore x Stroke:
|
66 x 50.6 mm
|
|
Cooling System:
|
Air cooled
|
|
Compression Ratio:
|
10.6 :1
|
|
Lubrication:
|
Pressure pump
|
|
Induction:
|
2x Dell'Orto PHBH 28 carburetors
|
|
Ignition:
|
Electronic Motoplat double pick-up
|
|
Starting:
|
Electric
|
|
Max Power:
|
22 kW / 30 hp @ 8200 rpm
|
|
Max Torque:
|
30 Nm / 3.1 kgf-m @ 6200 rpm
|
|
Clutch:
|
Dry single plate
|
|
Transmission:
|
5 Speed
|
|
Final Drive:
|
Shaft
|
|
Front Suspension:
|
Moto Guzzi hydropneumatic telescopic fork with pressure equalizer
|
|
Rear Suspension:
|
Swinging fork, light alloy die-casting, with Bitubo adjustable shock-absorber
|
|
Front Brakes:
|
2x 270mm discs
|
|
Rear Brakes:
|
Single 260mm disc
|
|
Wheels:
|
Spokes with light a
|
|
Front Tyre:
|
100/90 H18
|
|
Rear Tyre:
|
130/90 H16
|
|
Dry Weight:
|
175 kg / 386 lbs
|
|
Fuel Capacity:
|
16 Litres / 4.2 US gal
|
|
Standing ¼ Mile:
|
16.2 sec / 123.2 km/h
|
|
Top Speed:
|
145.8 km/h
|
