KTM Freeride 250R (2016-17) technical specifications

KTM Freeride 250R technical specifications

KTM Freeride 250R is produced in 2016-17. Engine is Two stroke, single cylinder, displacement 249 cc / 15.2 cu-in , produces power NA and NA. KTM Freeride 250R weighs 92.5 kg / 204 lbs. KTM Freeride 250R has 3 photos.

Technical specifications

+ Add to 'Compare list'
Model: Freeride 250R
Years: 2016-17
Engine: Two stroke, single cylinder
Capacity: 249 cc / 15.2 cu-in
Bore x Stroke: 66.4 X 72 mm
Cooling System: Liquid Cooled
Compression Ratio: 12.3:1
Induction: Carburettor
Ignition: Contactless, controlled, fully electronic ignition system with digital ignition timing adjustment, type Kokusan
Starting: Electric
Max Power: NA
Max Torque: NA
Clutch: Wet multi-disc clutch, Brembo hydraulics
Transmission: 6 Speed, claw shifted
Final Drive: Chain 5/8 x 1/4" X Ring
Primary Ratio: 26:72
Frame: Perimeter steel-aluminium composite frame
Front Suspension: WP Suspension4357 MXMA
Front Wheel Travel: 250 mm / 9.8 in
Rear Suspension: WP-PDS shock absorber,
Rear Wheel Travel: 280 mm / 11.0 in
Front Brakes: Single 260mm disc 2 piston caliper
Rear Brakes: Single 210mm disc 1 piston caliper
Front Tyre: 80/100-21
Rear Tyre: 110/90-19
Rake: 23.0°
Wheelbase: 1418 mm / 55.8 in
Seat Height: 915 mm / 36.0 in
Steering Head Angle: 67°
Ground Clarence: 325 mm / 12.7 in
Dry Weight: 92.5 kg / 204 lbs
Fuel Capacity: 7.0 Litres / 1.85 US gal
