KTM 790 Duke (2025) technical specifications

KTM 790 Duke is produced in 2025. Engine is Four stroke, parallel twin cylinder, DOHC, 4 valve per cylinder, displacement 799 cc / 48.7 cu-in , produces power 77 kW / 105 hp @ 9000 rpm A2 Licence: 70 kW / 94 hp @ 8000 and 87 Nm / 63.4 lb-ft @ 8000 rpm. KTM 790 Duke weighs 169 kg / 372.6 lbs. KTM 790 Duke has 4 photos.

Technical specifications

+ Add to 'Compare list'

Model:	790 Duke
Years:	2025
Engine:	Four stroke, parallel twin cylinder, DOHC, 4 valve per cylinder
Capacity:	799 cc / 48.7 cu-in
Bore x Stroke:	88 mm x 65.7 mm
Cooling System:	Liquid cooled with water/oil heat exchanger
Compression Ratio:	12.7:1
Exhaust:	Stainless steel primary and secondary silencer
Emission:	EURO 5+
Lubrication:	Forced oil lubrication with 2 oil pumps
Induction:	DKK Dell?Orto fuel injection with 46mm throttle body
Ignition:	Bosch EMS with RBW
Starting:	Electric
Max Power:	77 kW / 105 hp @ 9000 rpm A2 Licence: 70 kW / 94 hp @ 8000
Max Torque:	87 Nm / 63.4 lb-ft @ 8000 rpm
Clutch:	PASC antihopping clutch, mechanically operated
Transmission:	6-speed (quickshifter optional)
Final Drive:	Chain 520 X-Ring
Primary Drive:	39:75
Secondary Gear Ratio:	16:41
Frame:	Chromium-Molybdenum-Steel frame using the engine as stressed element, powder coated
Front Suspension:	43mm Non-adjustable inverted WP APEX fork
Front Wheel Travel:	140 mm / 5.5 in
Rear Suspension:	Linkage-free, cantilevered spring-preload adjustable WP Apex shock
Rear Wheel Travel:	150 mm / 5.9 in
Front Brakes:	2 x 300mm discs, radially mounted 4 piston caliper
Rear Brakes:	Single 240mm disc, 2 piston floating caliper
ABS:	Bosch 9.1 MP (incl. Cornering-ABS and super moto mode, disengageable)
Wheels:	Cast aluminium
Front Wheel:	3.50 x 17 in
Rear Wheel:	5.50 x 17 in
Front Tyre:	120/70 x 17
Rear Tyre:	180/55 x 17
Rake:	24?
Trail:	99 mm / 3.9 in
Steering Head Angle:	66?
Dimensions:	Length 2062 mm / 81.2 in Width 904 mm / 35.6 in Height 1059 mm / 41.7 in
Wheel base:	1475 ? 15 mm / 58 in
Seat Height:	825 mm / 32.5 in
Ground Clearance:	186 mm / 7.3 in
Dry Weight:	169 kg / 372.6 lbs
Wet Weight:	187.7 kg / 414 lbs
Fuel Capacity:	14 Litres / 3.7 US gal
