KTM 690 SMC R (2026) technical specifications

KTM 690 SMC R is produced in 2026. Engine is Single cylinder, 4-stroke, SOHC, 4-valve, displacement 692.7 cc / 42.2 cu in , produces power 79 hp / 58.1 kW and 73 Nm / 54 lb-ft. KTM 690 SMC R wet weight is 162 kg / 357 lbs. KTM 690 SMC R has 5 photos.

Technical specifications

+ Add to 'Compare list'

Model:	690 SMC R
Years:	2026
Engine:	Single cylinder, 4-stroke, SOHC, 4-valve
Capacity:	692.7 cc / 42.2 cu in
Bore x Stroke:
Compression Ratio:
Cooling System:	Liquid cooled
Lubrication System:	Pressure lubrication with 2 oil pumps
Emission:	Euro5 - 96 g/km
Exhaust:	Stainless steel primary and secondary silencer
Induction:	Keihin EFI (throttle body 50 mm)
Ignition:	Keihin EMS with RBW, double ignition
Starting:	Electric
Max Power:	79 hp / 58.1 kW
Max Torque:	73 Nm / 54 lb-ft
Clutch:	APTC slipper clutch, hydraulically actuated
Transmission:	6-Speed
Final Drive:	Chain, 520 X-Ring
Frame:	Chrome-moly tubular space frame, powder-coated
Sub Frame:	Self-supporting plastic tank
Handlebar:	808 mm wide rubber mounted
Front Suspension:	48 mm WP APEX-USD, compression and rebound adjustable
Front Wheel Travel:	224 mm / 8.8 in
Rear Suspension:	WP APEX with Pro-Lever linkage
Rear Wheel Travel:	240 mm / 9.4 in
Front Brakes:	Single 300mm disc, Brembo four-piston radial fixed calliper
Rear Brakes:	Single 240 mm disc, Brembo single piston floating caliper
ABS:	Two-channel Bosch 9.1 MP ABS (incl. Cornering ABS and Supermoto mode Disengegable)
Front Wheel:	Spoked wheels with aluminum tubeless rims 3.50 ? 17
Rear Wheel:	Spoked wheels with aluminum tubeless rims 5.00 ? 17
Front Tyre:	120/70 ZR 17
Rear Tyre:	160/60 ZR 17
Steering Head Angle:	63.6?
Trail:	110 mm / 4.3 in
Wheelbase:	1476 mm / 58.1 in
Ground Clearance:	237 mm / 9.3 in
Seat Height:	899 mm / 35.4 in
Wet Weight:	162 kg / 357 lbs
Fuel Capacity:	13.3 Litres / 3.5 US gal
