KTM 690 Enduro R (2026) technical specifications

KTM 690 Enduro R is produced in 2026. Engine is Single cylinder, 4-stroke, SOHC, 4-valve, displacement 692.7 cc / 42.27 cu in , produces power 79 hp / 58.1 kW and 73 Nm / 54 lb-ft. KTM 690 Enduro R wet weight is 162 kg / 357 lbs. KTM 690 Enduro R has 5 photos.

Technical specifications

+ Add to 'Compare list'

Model:	690 Enduro R
Years:	2026
Engine:	Single cylinder, 4-stroke, SOHC, 4-valve
Capacity:	692.7 cc / 42.27 cu in
Bore x Stroke:
Compression Ratio:
Cooling System:	Liquid cooled
Lubrication System:	Pressure lubrication with 2 oil pumps
Exhaust:	Stainless steel primary and secondary silencer
Induction:	Keihin EFI (throttle body 50 mm)
Ignition:	Keihin EMS with RBW, double ignition
Starting:	Electric
Max Power:	79 hp / 58.1 kW
Max Torque:	73 Nm / 54 lb-ft
Clutch:	PASC? slipper clutch, hydraulically operated
Transmission:	6-Speed
Final Drive:	Chain, 520 X-ring
Frame:	Chromium-molybdenum-steel trellis frame, powder coated
Sub Frame:	Self-supporting plastic tank
Front Suspension:	WP USD XPLOR 48 forks, compression and rebound adjustable
Front Wheel Travel:	265 mm / 10.4 in
Rear Suspension:	WP XPLOR shock absorber with Pro-Lever linkage, preload adjuster
Rear Wheel Travel:	250 mm / 9.8 in
Front Brakes:	Single 300 mm disc, Brembo 2 piston floating caliper
Rear Brakes:	Single 240 mm disc, Brembo single piston floating caliper
ABS:	Bosch 9.1 MP (incl. Cornering ABS and offroad mode, disengageable)
Front Wheel:	Spoked wheels with aluminum rims, 1.85 ? 21″
Rear Wheel:	Spoked wheels with aluminum rims, 2.50 ? 18″
Front Tyre:	90/90 -21
Rear Tyre:	140/80 -18
Steering Head Angle:	62.3?
Trail:	120 mm / 4.7 in
Wheelbase:	1506 mm / 59.3 in
Ground Clearance:	265 mm / 10.4 in
Seat Height:	935 mm / 36.8 in
Wet Weight:	162 kg / 357 lbs
Fuel Capacity:	13.3 Litres / 3.5 US gal
