KTM 640 LC4 Adventure (2002-03) technical specifications

KTM 640 LC4 Adventure technical specifications

KTM 640 LC4 Adventure is produced in 2002-03. Engine is Four stroke, single Cylinder. SOHC, 4 Valve per cylinder,, displacement 624.6 cc / 38.1 cu in , produces power 35.7 kW / 49 hp @ 7500 rpm and 52 Nm / 5.3 kgf-m / 38.4 lb-ft @ 5500 rpm. KTM 640 LC4 Adventure weighs 154 kg / 340 lbs. KTM 640 LC4 Adventure has 5 photos.

Technical specifications

+ Add to 'Compare list'
Model: 640 LC4 Adventure
Years: 2002-03
Engine: Four stroke, single Cylinder. SOHC, 4 Valve per cylinder,
Capacity: 624.6 cc / 38.1 cu in
Bore x Stroke: 101 x 78 mm
Compression Ratio: 11.0:1
Cooling System: Liquid cooled
Induction: Mikuni BST 40
Ignition: Contactless DC-CDI ignition with digital advanced system, KOKUSAN
Spark Plug: NGK DPR8 EA-9
Battery: 12V 8Ah, maintenance free
Starting: Kick & electric
Max Power: 35.7 kW / 49 hp @ 7500 rpm
Max Torque: 52 Nm / 5.3 kgf-m / 38.4 lb-ft @ 5500 rpm
Clutch: Wet, multiplate
Transmission: 5 Speed, claw shifted
Primary Drive Ratio: 30:81
Gear Ratios: 1st 14:35 / 2nd 15:24 / 3rd 18:21 / 4th 20:19 / 5th 22:18
Final Drive Ratio: 16:40
Final Drive: Chain
Frame: Central chrome-moly-steel frame
Front Suspension: 50 mm WP upside-down forks
Front Wheel Travel: 300 mm / 11.8 in
Rear Suspension: WP monoshock
Rear Wheel Travel: 320 mm / 12.6 in
Front Brakes: Single 300mm disc, 4piston floating caliper
Rear Brakes: Single 220mm disc, 1 piston floating caliper
Front Tyre: 90/90 - 21 54S Enduro 3
Rear Tyre: 140/80 - 18 70R Enduro 3
Steering Head Angle: 62.5o
Wheelbase: 1510 mm / 59.4 in
Ground Clearance: 320 mm / 12.6 in
Seat Height: 945 mm / 37.2 in
Dry Weight: 154 kg / 340 lbs
GVWR: 380 kg / 839 lbs
Fuel Capacity: 28 L / 7.4 US gal / 6.2 Imp gal
Fuel Reserve: 3.8 L / 1.0 US gal / 0.8 Imp gal
Manual: blackbears.ru
