KTM 450 Rally Replica (2026) technical specifications

KTM 450 Rally Replica is produced in 2026. Engine is Four stroke, single cylinder, SOHC, 4 valves, displacement 449.3 cc / 27.4 in KTM 450 Rally Replica has 6 photos.

Technical specifications

+ Add to 'Compare list'

Model:	450 Rally Replica
Years:	2026
Production:	150 Rally Replica units + 5 Rally Replica Sanders Edition
Engine:	Four stroke, single cylinder, SOHC, 4 valves
Capacity:	449.3 cc / 27.4 in
Bore x Stroke:	95 x 63.4 mm
Compression Ratio:	12.6:1
Cooling System:	Liquid Cooled
Lubrication:	Forced oil lubrication with 2 oil pumps
EMS:	Kokusan
Starting:	Electric
Clutch:	Wet multi-disc clutch, hydraulically operated
Transmission:	6 Speed
Final Drive:	Chain, 5/8 x 1/4"
Frame:	Chromium-Molybdenum trellis frame, powder coated Subframe Self-supporting plastic tank Handlebar Aluminium, tapered, ? 28 / 22 mm
Front Suspension:	WP-USD ? 48 mm, XACT PRO 7548
Front Wheel Travel:	304 mm / 11.96 in
Rear Suspension:	WP-XACT PRO 7750 monoshock
Rear Wheel Travel:	280 mm / 11.02 in
Front Brakes:	Single 300 mm disc, Brembo two-piston, floating caliper
Rear Brakes:	Single 240 mm disc, 1 piston, floating caliper
Wheels:	Spoked wheels with aluminium rims
Front Wheel:	21 in
Rear Wheel:	18 in
Front Tyre:	90/90 - 2154S TT, Michelin T63
Fuel Capacity:	35 L / 9.2 US gal
