Technical specifications
|
| Model: |
360 EXC |
| Years: |
1995-96 |
|
Engine:
|
Two stroke, single cylinder
|
|
Capacity:
|
353.7 cc / 21.6 cu in
|
|
Bore x Stroke:
|
78 x 74 mm
|
|
Cooling System:
|
Liquid cooled
|
|
Fuel:
|
1:50 - 1.60 when using high grade two stroke oil
|
|
Ignition:
|
KOKUSAN 2K-2
|
|
Starting:
|
Kick
|
|
Spark Plug:
|
NGK BR 8 ECM, Electrode gap 0.6 mm (0.024 in)
|
|
Clutch:
|
Wet, multiplate
|
|
Transmission:
|
5 Speed
|
|
Final Drive:
|
Chain
|
|
Primary Drive Ratio:
|
25:72
|
|
Gear Ratio:
|
1st 15:29 1 / 2nd 18:26 / 3rd 19:22 / 4th 21:20 / 5th 23:18
|
|
Final Drive Ratio:
|
14:52
|
|
Front Suspension:
|
43mm Upside down forks and shock
|
|
Front Wheel Travel:
|
125 mm / 4.9 in
|
|
Rear Suspension:
|
Fully adjustable White Power
|
|
Rear Wheel Travel:
|
240 mm / 9.4 in
|
|
Front Brakes:
|
Single disc
|
|
Rear Brakes:
|
Single disc
|
|
Front Tyre:
|
90/90 - 21
|
|
Rear Tyre:
|
140/80 - 18
|
|
Dry Weight:
|
113 kg / 249 lbs
|
|
Fuel Capacity:
|
9 L / 2.4 US gal / 1.9 Imp gal
|
