KTM 250 Duke (2024) technical specifications

KTM 250 Duke is produced in 2024. Engine is Four stroke, single cylinder, DOHC, 4 valves per cylinder, displacement 248.8 cc / 15.2 cu in , produces power 23.0 kW / 30.87 hp and 25 Nm / 18.4 lb-ft. KTM 250 Duke weighs 165 kg / 364 lbs. KTM 250 Duke has 5 photos.

Technical specifications

+ Add to 'Compare list'

Model:	250 Duke
Years:	2024
Engine:	Four stroke, single cylinder, DOHC, 4 valves per cylinder
Capacity:	248.8 cc / 15.2 cu in
Bore x Stroke:	72 x 61.1 mm
Compression Ratio:
Cooling System:	Liquid cooled
Lubrication:	Wet sump
Exhaust:
Induction:
Spark Plug:
Ignition:	Bosch EMS with RBW
Battery:
Starter:	Electric
Max Power:	23.0 kW / 30.87 hp
Max Torque:	25 Nm / 18.4 lb-ft
Clutch:	PASC antihopping clutch, mechanically operated
Transmission:	6 Speed
Primary Drive Ratio:
Gear Ratios:
Final Drive Ratio:
Final Drive:	Chain 520 X-Ring
Frame:	Steel trellis frame, powder coated
Front Suspension:	WP-APEX Ø 43 mm.
Front Wheel Travel:	150 mm / 5.9 in
Rear Suspension:	WP-APEX Monoshock
Rear Wheel Travel:	150 mm / 5.9 in
Front Brakes:	Single 320 mm disc, four-piston radial fixed calliper, brake disc
Rear Brakes:	Single 240 mm disc, 2 piston caliper, floating
ABS:	Bosch 10 MB Two Channel ABS (disengageable)
Front Wheel:
Rear Wheel:
Front Tyre:
Rear Tyre:
Steering Head Angle:
Trail:
Dimensions:
Wheelbase:
Ground Clearance:
Seat Height:	800 mm / 31.5 in
Dry Weight:	165 kg / 364 lbs
Fuel Capacity:
