KTM 1290 Super Duke R (2019) technical specifications

KTM 1290 Super Duke R technical specifications

KTM 1290 Super Duke R is produced in 2019. Engine is Four stroke, 75°V-twin cylinder, DOHC, 4 valves per cylinder, displacement 1301 cc / 79.3 cu-in , produces power 130.2 kW / 177 hp @ 8870 rpm and 141 Nm / 14.4 kgf-m / 104 ft-lb @ 7000rpm. KTM 1290 Super Duke R weighs 195 kg / 430 lbs. KTM 1290 Super Duke R has 5 photos.

Technical specifications

+ Add to 'Compare list'
Model: 1290 Super Duke R
Years: 2019
Engine: Four stroke, 75°V-twin cylinder, DOHC, 4 valves per cylinder
Capacity: 1301 cc / 79.3 cu-in
Bore x Stroke: 108 x 71 mm
Lubrication: Pressure lubrication with 3 Eaton pumps
Compression Ratio: 13.2:1
Cooling System: Liquid cooling
Emissions: Euro 4 compliant
Engine Management: Keihin EMS with RWB, double ignition and cruise control
Ignition: Contactless, controlled, fully electronic ignition system with digital ignition timing adjustment
Battery: 12V 11.2Ah
Starting: Electric
Max Power: 130.2 kW / 177 hp @ 8870 rpm
Max Torque: 141 Nm / 14.4 kgf-m / 104 ft-lb @ 7000rpm
Clutch: PASC slipper clutch, hydraulically operated
Transmission: 6 Speed
Primary Drive Ratio: 40:76
Final Drive Ratio: 17:38
Final Drive: Chain 520 X-ring
Frame: Chromium-Molybdenum steel trellis frame, powder coated
Front Suspension: WP-USD Ø 48 mm fork
Font Wheel Travel: 125 mm / 4.7 in
Rear Suspension: WP-Monoshock
Rear Wheel Travel: 156 mm / 6.1 in
Front Brakes: 2 x 320mm Floating discs, Brembo monoblock 4 piston radial fixed calipers
Rear Brakes: Single disc, Brembo 2 piston fixed calipers
ABS: Two-channel Bosch 9.1 MP ABS (incl. Cornering ABS and Supermoto mode Disengegable)
Front Wheel: 17x 3.5 in, cast aluminum alloy
Rear Wheel: 17x 6.0 in, cast aluminum alloy
Front Tyre: 120/70 ZR17 Metzeler M7RR
Rear Tyre: 190/55 ZR17 Metzeler M7RR
Steering Head Angle: 65.1°
Rake: 24.9°
Trail: 102 mm / 4.2 in
Wheelbase: 1482 mm / 58.3 in
Ground Clearance: 141 mm / 5.5 in
Seat Height: 835 mm / 32.9 in
Dry Weight: 195 kg / 430 lbs
Fuel Capacity: 18 Litres / 4.8 US gal / 4.0 Imp gal Unleaded premium fuel (95 RON)
