KTM 125 Duke (2019-20) technical specifications

KTM 125 Duke is produced in 2019-20. Engine is Four stroke, single cylinder, DOHC, 4 valves, displacement 124.7 cc / 7.6 cu-in , produces power 11.3 kW / 15 hp @ 10500 rpm and 12 Nm / 8.85 ft-lb @ 8000 rpm. KTM 125 Duke weighs 141.4 kg / 311.7 lbs. KTM 125 Duke has 4 photos.

Technical specifications

+ Add to 'Compare list'

Model:	125 Duke
Years:	2019-20
Engine:	Four stroke, single cylinder, DOHC, 4 valves
Capacity:	124.7 cc / 7.6 cu-in
Bore x Stroke:	58 x 47.2 mm
Cooling System:	Liquid cooled
Compression Ratio:	14.5:1
Lubrication:	Wet sump
Induction:	Bosch electronic fuel injection
Emission:	EURO5
Ignition:	Contactless, controlled, fully electronic ignition system with digital ignition timing adjustment
Starting:	Electric
Max Power:	11.3 kW / 15 hp @ 10500 rpm
Max Torque:	12 Nm / 8.85 ft-lb @ 8000 rpm
Clutch:	Wet multi-disc, mechanically actuated
Transmission:	6 Speed
Final Drive:	Chain 520 X-ring
Frame:	Steel trellis frame, powder coated
Front Suspension:	43 mm WP-USD, AER 43
Front Wheel Travel:	140 mm / 5.5 in
Rear Suspension:	WP Monoshock
Rear Wheel Travel:	162 mm / 6.4 in
Front Brakes:	Single 300 mm disc, 4 piston radial fixed caliper
Rear Brakes:	Single 230 mm disc, single piston floating caliper
ABS:	Bosch 10 ML Single Channel ABS
Front Tyre:	110/70 -17
Rear Tyre:	150/60 -17
Steering Head Angle:	65°
Wheelbase:	1357 mm / 53.4 in
Ground Clearance:	155 mm / 6.1 in
Seat Height:	818 mm / 32.2 in
Dry Weight:	141.4 kg / 311.7 lbs
Fuel Capacity:	11 Litres / 3.0 US gal
