KTM 1190 Adventure R (2015) technical specifications

KTM 1190 Adventure R technical specifications

KTM 1190 Adventure R is produced in 2015. Engine is Four stroke, 75°V-twin cylinder, DOHC, 4 valves per cylinder, displacement 1195 cc / 72.9 cu-in , produces power 147.5 hp / 107.7 kW @ 9500 rpm and 92.2 lb-ft / 124.8 Nm @ 7500 rpm. KTM 1190 Adventure R weighs 217 kg / 478.4 lb. KTM 1190 Adventure R has 6 photos.

Technical specifications

+ Add to 'Compare list'
Model: 1190 Adventure R
Years: 2015
Engine: Four stroke, 75°V-twin cylinder, DOHC, 4 valves per cylinder
Capacity: 1195 cc / 72.9 cu-in
Bore x Stroke: 105 x 69 mm
Cooling System: Liquid cooling
Compression Ratio: 12.5:1
Lubrication: Forced oil lubrication with 3 rotor pumps
Induction: EFI, ride by wire
Ignition: Contactless, controlled, fully electronic ignition system with digital ignition timing adjustment
Starting: Electric
Max Power: 147.5 hp / 107.7 kW @ 9500 rpm
Max Torque: 92.2 lb-ft / 124.8 Nm @ 7500 rpm
Clutch: Wet multi-disc clutch, hydraulically operated
Transmission: 6 Speed
Final Drive: Chain 5/8 x 5/16" X Ring
Primary gear ratio: 40:76
Secondary gear ratio: 17:42
Frame: Tubular space frame made from chrome molybdenum steel, powder-coated
Front Suspension: 48mm WP USD forks
Front Wheel Travel: 220 mm / 8.6 in
Rear Suspension: WP-PDS rear shock, hydraulic spring preload.
Rear Wheel Travel: 220 mm / 8.6 in
Front Brakes: 2x 320mm discs 4 piston calipers
Rear Brakes: Single 267mm disc 2 piston caliper
Front Tyre: 90 / 90 ZR21
Rear Tyre: 150/60 ZR18
Steering Head Angle: 64°
Rake: 26.0°
Trail: 129.5 mm / 5.1 in.
Wheelbase: 1580 mm / 62.2 in
Seat Height: 890 mm / 35 in
Ground Clearance: 250 mm / 9.8 in (unloaded)
Dry Weight: 217 kg / 478.4 lb
Fuel Capacity: 23 Litres / 6.08 gal
