KTM 1090 Adventure R (2019) technical specifications

KTM 1090 Adventure R technical specifications

KTM 1090 Adventure R is produced in 2019. Engine is Four stroke, 75°V-twin cylinder, DOHC, 4 valves per cylinder, displacement 1050 cc / 64.0 cu-in , produces power 125 hp / 91.2 kW @ 8500 rpm and 109 Nm / 80.4 lb.-ft. @ 6500 rpm. KTM 1090 Adventure R weighs 207 kg / 456.4 lbs. KTM 1090 Adventure R has 3 photos.

Technical specifications

+ Add to 'Compare list'
Model: 1090 Adventure R
Years: 2019
Engine: Four stroke, 75°V-twin cylinder, DOHC, 4 valves per cylinder
Capacity: 1050 cc / 64.0 cu-in
Bore x Stroke: 103 x 63 mm
Cooling System: Liquid cooling system, continuous circulation of cooling liquid with water pump
Compression Ratio: -
Lubrication: Forced oil lubrication with 3 rotor pumps
Induction: EFI, ride by wire
Ignition: Keihin EMS with RBW, twin ignition
Starting: Electric
Max Power: 125 hp / 91.2 kW @ 8500 rpm
Max Torque: 109 Nm / 80.4 lb.-ft. @ 6500 rpm
Clutch: PASC (TM) slipper clutch, hydraulically actuated
Transmission: 6 Speed
Final Drive: Chain X-Ring 5/8 x 5/16″
Primary Gear Ratio: 40:76
Secondary Gear Ratio: 17:42
Frame: Chromium-Molybdenum steel trellis frame, powder coated
Front Suspension: 48mm WP Suspension Up Side Down
Front Wheel Travel: 220 mm / 8.7 in
Rear Suspension: WP-PDS Monoshock
Rear Wheel Travel: 220 mm / 8.7 in
Front Brakes: 2x 320mm discs 4 piston calipers
Rear Brakes: Single 267mm disc 2 piston caliper
ABS: Bosch 9M+ Two-channel ABS (incl. offroad mode, disengageable)
Front Tyre: 90/90 R21 Continental TKC 80 Twinduro
Rear Tyre: 150/70 R18 Continental TKC 80 Twinduro
Rake: 26.0°
Steering Head Angle: 64°
Trail: 119.8 mm / 4.72 in.
Wheelbase: 1580 mm / 62.2 in
Seat Height: 890 mm / 35.0 in
Ground Clearance: 250 mm / 9.8 in
Dry Weight: 207 kg / 456.4 lbs
Fuel Capacity: 23 Litres / 6.08 gal
