Kawasaki ZX-6RR (2003) technical specifications

Kawasaki ZX-6RR technical specifications

Kawasaki ZX-6RR is produced in 2003. Engine is Four stroke, transverse four cylinder, DOHC, 4 valves per cylinder., displacement 599 cc / 36.6 cub in , produces power 86.8 kW / 118 hp @ 13200 rpm and 64.4 Nm / 6.6 kgf-m / 47.5 lb-ft @ 12000 rpm. Kawasaki ZX-6RR top speed is 266 km/h / 165 mph. Kawasaki ZX-6RR weighs 161 kg / 355 lbs. Kawasaki ZX-6RR has 4 photos.

Technical specifications

+ Add to 'Compare list'
Model: ZX-6RR
Years: 2003
Engine: Four stroke, transverse four cylinder, DOHC, 4 valves per cylinder.
Capacity: 599 cc / 36.6 cub in
Bore x Stroke: 67 x 42.5 mm
Compression Ratio: 13.0:1
Cooling System: Liquid cooled,
Induction: Fuel injection with 38mm throttle bodies
Lubrication: Wet sump
Ignition: Digital
Starting: Electric
Max Power: 86.8 kW / 118 hp @ 13200 rpm
Max Torque: 64.4 Nm / 6.6 kgf-m / 47.5 lb-ft @ 12000 rpm
Clutch: Wet, multiple discs, cable operated
Transmission: 6 Speed
Final Drive: Chain
Gear Ratios: 1st 2.92 / 2nd 2.06 / 3rd 1.72 / 4th 1.45 / 5th 1.27 / 6th 1.15:1
Frame: Perimeter, pressed-aluminium
Front Suspension: 41mm inverted cartridge fork with adjustable preload, stepless rebound and compression damping and top-out springs
Front Wheel Travel: 119 mm / 4.7 in
Rear Suspension: Bottom-Link Uni-Trak with gas charged shock, stepless rebound and compression damping, spring preload adjustability and top-out springs
Rear Wheel Travel: 133 mm / 5.2 in
Front Brakes: 2 x 280mm discs, 4 piston calipers
Rear Brakes: Single 220mm disc, 1 piston caliper
Front Tyre: 120/65 ZR17
Rear Tyre: 180/55 ZR17
Rake: 25°
Trail: 85 mm / 3.3 in.
Dimensions: Length 2075 mm / 81.7 in Width 714 mm / 28.1 in Height 1120 mm / 44.1 in
Wheelbase: 1400 mm / 55.1 in.
Seat Height: 820 mm / 32.3 in.
Dry-Weight: 161 kg / 355 lbs
Fuel Capacity: 18 Litres / 4.8 US gal
Standing ¼ Mile: 10.9 sec / 204.9 km/h / 127.3 mph
Top Speed: 266 km/h / 165 mph
