Kawasaki W 230 (2026) technical specifications

Kawasaki W 230 is produced in 2026. Engine is Four stroke, single cylinder, SOHC, 2 valve, displacement 233 cc , produces power 17 hp / 12.7 kW @ 7000 rpm and 19 Nm / 14 lb-ft @ 5800 rpm. Kawasaki W 230 weighs 133 kg / 293.3 lbs. Kawasaki W 230 has 5 photos.

Technical specifications

+ Add to 'Compare list'

Model:	W 230
Years:	2026
Engine:	Four stroke, single cylinder, SOHC, 2 valve
Capacity:	233 cc
Bore x Stroke:	67 x 66 mm
Cooling System:	Air cooled
Compression Ratio:	9.0:1
Induction:	DFI? with 32mm throttle body
Ignition:	TCBI with Digital Advance
Starting:	Electric
Max Power:	17 hp / 12.7 kW @ 7000 rpm
Max Torque:	19 Nm / 14 lb-ft @ 5800 rpm
Clutch:	Wet multi-disc, manual
Transmission:	6 Speed, return shift
Final Drive:	Sealed chain
Frame:	Semi-double cradle, steel
Front Suspension:	37mm Telescopic fork
Front Wheel Travel:	117 mm / 4.6 in
Rear Suspension:	Twin shocks with spring preload adjustability
Rear Wheel Travel:	94 mm / 3.7 in
Front Brakes:	Single 265 mm disc with 2-piston calipers
Rear Brakes:	Single 220 mm disc with 1-piston caliper
ABS:	Standard
Front Tyre:	90/90-18
Rear Tyre:	110/90-17
Rake:	27?
Trail:	94 mm / 3.7 in
Dimensions:	Length 2123 mm / 83.6 in Width 798 mm / 31.4 in Height 1090 mm / 42.9 in
Wheelbase:	1415 mm / 55.7 in
Seat Height:	744 mm / 29.3 in
Ground Clearance:	150 mm / 5.9 in
Dry Weight:	133 kg / 293.3 lbs
Wet Weight:	143 kg / 315.3 lbs
Fuel Capacity:	11.7 Litres / 3.1 US gal
