Kawasaki F9 350 Bighorn (1972-75) technical specifications
Kawasaki F9 350 Bighorn is produced in 1972-75. Engine is Two stroke, single cylinder, rotary valves, displacement 346 cc / 21 cu-in , produces power 33 hp / 24.2 kW @ 6500 rpm and 38 Nm / 28 lb-ft @ 5500. Kawasaki F9 350 Bighorn wet weight is 134 kg / 295 lbs. Kawasaki F9 350 Bighorn has 1 photos.
Technical specifications
+ Add to 'Compare list'| Model: | F9 350 Bighorn |
| Years: | 1972-75 |
| Engine: | Two stroke, single cylinder, rotary valves |
| Capacity: | 346 cc / 21 cu-in |
| Bore x Stroke: | 80.5 x 68 mm |
| Cooling System: | Air cooled |
| Compression Ratio: | 6.8:1 |
| Induction: | 32mm Mikuni carburetor |
| Ignition: | Battery and coil |
| Starting: | Kick |
| Max Power: | 33 hp / 24.2 kW @ 6500 rpm |
| Max Torque: | 38 Nm / 28 lb-ft @ 5500 |
| Clutch: | Wet, multi-disc |
| Transmission: | 5 Speed |
| Final Drive: | Chain |
| Frame: | Double cradle tubular |
| Front Suspension: | Telescopic Hydraulic forks |
| Rear Suspension: | Dual shocks, Swing arm |
| Front Brakes: | 152mm Drum |
| Rear Brakes: | 152mm Drum |
| Front Tyre: | 3.00-21 |
| Rear Tyre: | 4.00 -18 |
| Wheelbase: | 1410 mm / 55.5 in |
| Seat Height: | 800 mm / 31.5 in |
| Ground Clearance: | 216 mm / 8.5 in |
| Wet Weight: | 134 kg / 295 lbs |
| Fuel Capacity: | 11 Litres / 2.9 US gal |
