2005 Jawa 125 Dakar technical specifications

Technical specifications

Model: 125 Dakar
Years: 2005
Engine: Four stroke, single cylinder, 2 valves
Capacity: 124 cc / 7.6 cu in
Bore x Stroke: 56.5 x 49.5 mm
Compression Ratio: 9.0:1
Cooling System: Air cooled
Ignition: Electronic
Starting: Electric & kick
Max Power: 9.2 kW / 12.6 hp @ 8200 rpm
Max Torque: 9.2 Nm / 0.93 kgf-m / 6.8 ft. lbs @ 7000 rpm
Transmission: 5 Speed
Final Drive: Chain
Front Suspension: Hydraulic telescopic forks
Rear Suspension: Mono shock
Front Brakes: Single Ø220 mm disc, 1 piston caliper
Rear Brakes: Single Ø180 mm, 1 piston caliper
Front Wheel: 3.00-19
Rear Wheel: 3.50-16
Wheelbase: 1330 mm / 52.4 in
Seat Height: 830 mm / 32.7 in
Dry Weight: 99 kg / 218 lbs
Fuel Capacity: 6.5 L / 1.7 US gal
Fuel Reserve: 1.2 L / 0.3 US gal
