Indian FTR 1200 Rally (2023) technical specifications

Indian FTR 1200 Rally technical specifications

Indian FTR 1200 Rally is produced in 2023. Engine is Four stroke, 60° V Twin , DOHC, 4 valves per cylinder, graded buckets, displacement 1203 cc / 73 cu-in , produces power 120 hp / 89.4 kW @ 6000 rpm and 117.9 Nm / 87 lb-ft @ 6000 rpm. Indian FTR 1200 Rally weighs 222 kg / 488 lbs. Indian FTR 1200 Rally has 6 photos.

Technical specifications

+ Add to 'Compare list'
Model: FTR 1200 Rally
Years: 2023
Engine: Four stroke, 60° V Twin , DOHC, 4 valves per cylinder, graded buckets
Capacity: 1203 cc / 73 cu-in
Bore x Stroke: 102 x 73.6 mm
Compression Ratio: 12.5:1
Cooling System: Liquid Cooled
Induction: Electronic Fuel Injection closed loop, 60 mm bore
Emission: EURO5
Exhaust: 2-into-1
Starting: Electric
Max Power: 120 hp / 89.4 kW @ 6000 rpm
Max Torque: 117.9 Nm / 87 lb-ft @ 6000 rpm
Clutch: Assist & Slip, Multi-Plate
Transmission: 6 Speed
Final Drive: Chain
Final Drive Ratio: 2.647 : 1
Gear Ratios: 1st 12.270 : 1 2nd 8.341 : 1 3rd 6.646 : 1 4th 5.639 : 1 5th 4.985 : 1 6th 4.278 : 1
Primary Drive: Gear drive wet clutch
Lean Angle: 43°
Frame: Steel trellis
Front Suspension: 43 mm Inverted Telescopic Cartridge Fork
Front Wheel Travel: 150 mm / 5.9 in
Rear Suspension: Monotube IFP
Rear Wheel Travel: 150 mm / 5.9 in
Front Brakes: 2x 320mm t5 Rotor Brembo with 4-piston calipers
Rear Brakes: Single 260mm t5 Rotor Brembo with 2-piston calipers
ABS: Standard, option to disable
Wheels: Cast Aluminum
Front Wheel: 18 x 3.0
Rear Wheel: 19 x 4.25
Front Tyre: 120/70R19 M/C 60V M+S
Rear Tyre: 150/70R18 M/C 70V M+S
Rake: 26.3°
Trail: 130 mm / 5.1 in
Dimensions: Length 2286 mm / 90.0 in Width 867 mm / 34.1 in Height 1396 mm / 53.9 in
Wheelbase: 1524 mm / 60 in
Seat Height: 815 mm / 32.1 in
Ground Clearance: 170 mm / 6.5 in
Dry Weight: 222 kg / 488 lbs
Wet Weight: 236 kg / 520 lbs
Fuel Capacity: 12.9 Litres / 3.4 US gal
Standard Equipment: ABS, Cruise Control
