Husqvarna TE 510 (2004-05) technical specifications

Husqvarna TE 510 technical specifications

Husqvarna TE 510 is produced in 2004-05. Engine is Four stroke, single cylinder, DOHC, 4 valves, displacement 501 cc / 30.5 cu-in , produces power 59.8 hp / 44 kW @ 8000 rpm and 49 Nm / 56 lb-ft @ 6400 rpm. Husqvarna TE 510 weighs 117 kg / 258 lbs. Husqvarna TE 510 has 1 photos.

Technical specifications

+ Add to 'Compare list'
Model: TE 510
Years: 2004-05
Engine: Four stroke, single cylinder, DOHC, 4 valves
Capacity: 501 cc / 30.5 cu-in
Bore x Stroke: 97 x 67.8 mm
Cooling System: Liquid cooled
Compression Ratio: 12.5;1
Induction: 41mm Keihin MX carburetor
Ignition: CDI
Battery: 12 V - 6 Ah
Starting: Electric & kick
Max Power: 59.8 hp / 44 kW @ 8000 rpm
Max Torque: 49 Nm / 56 lb-ft @ 6400 rpm
Clutch: Wet / Multiplate / 6 spd
Transmission: 6 Speed
Final Drive: Chain
Gear Ratio: 1st 2.000 (28/14), 2nd 1.611 (29/18), 3rd 1.333 (24/18), 4th 1.086 (25/23), 5th 0.920 (23/25), 6th 0.814 (22/27)
Frame: Steel single tube cradle (round tubes); rear frame in light alloy
Front Suspension: Marzocchi "Upside-Down" telescopic hydraulic fork with advanced axle; compression and rebound stroke adjustment
Front Wheel Travel: 300 mm / 11.8 in
Rear Suspension: Sachs progressive "Soft Damp" type with single hydraulic shock absorber; spring preload adjustment, compression and rebound adjustment
Rear Wheel Travel: 320 mm / 12.6 in
Front Brakes: Single 260mm disc
Rear Brakes: Single 220mm disc
Front Tyre: 90/90-21
Rear Tyre: 140/80-18
Wheelbase: 1460 mm / 57.5 in
Seat Height: 975 mm / 38.4 in
Ground Clearance: 340 mm / 13.4 in
Dry Weight: 117 kg / 258 lbs
Fuel Capacity: 9.2 Litres / 2.4 US gal
