Husqvarna SMR 630 (2012-) technical specifications

Husqvarna SMR 630 technical specifications

Husqvarna SMR 630 is produced in 2012-. Engine is Four stroke, single cylinder, DOHC, 4 valves, displacement 600 cc / 36.6 cu-in , produces power and . Husqvarna SMR 630 wet weight is 148.3 kg / 326.9 lbs. Husqvarna SMR 630 has 2 photos.

Technical specifications

+ Add to 'Compare list'
Model: SMR 630
Years: 2012-
Engine: Four stroke, single cylinder, DOHC, 4 valves
Capacity: 600 cc / 36.6 cu-in
Bore x Stroke: 100 x 76.4 mm
Cooling System: Liquid cooled
Compression Ratio: 12.4:1
Induction: Electronic injection feed
Ignition: Electronic, inductive discharge, w/digital control
Starting: Electric
Max Power:
Max Torque:
Clutch: Wet, multiplate; hydraulic actuated
Transmission: 6 Speed
Final Drive: Chain
Gear Ratio: 1st 2,615 (34/13) / 2nd 1,812 (29/16) / 3rd 1,350 (27/20) / 4th 1,091 (24/22) / 5th 0,916 (22/24) / 6th 0,769 (20/26)
Frame: Main frame steel single tube cradle, Sub-frame aluminum
Front Suspension: 45mm Marzocchi Upside-Down" fork with advanced axle; rebound stroke adjustment
Front Wheel Travel: 250 mm / 9.8 in
Rear Suspension: Progressive "Soft Damp" type with single SACHS shock absorber; spring preload adjust, compression and rebound adjustment (compression stroke: double adjustment
Rear Wheel Travel: 290 mm / 11.4 in
Front Brakes: Single 300mm disc
Rear Brakes: Single 220mm disc
Front Tyre: 120/70 -17
Rear Tyre: 150/60-17
Wheelbase: 1495 mm / 58.8 in
Seat Height: 910mm / 35.8 in
Ground Clearance: 240 mm / 9.4 in
Wet Weight: 148.3 kg / 326.9 lbs
Fuel Capacity: 12 Litres / 3.1 US gal
