Honda X-ADV (2021) technical specifications

Honda X-ADV is produced in 2021. Engine is Four stroke , Parallel twin, SOHC, 4 valves per cylinder, displacement 745 cc / 45.4 cu-in , produces power 43.1 kW / 57.8 hp @ 6750 rpm and 69 Nm / 50.9 lb-ft @ 4750 rpm. Honda X-ADV wet weight is 236 kg / 520.2 lbs. Honda X-ADV has 7 photos.

Technical specifications

+ Add to 'Compare list'

Model:	X-ADV
Years:	2021
Engine:	Four stroke , Parallel twin, SOHC, 4 valves per cylinder
Capacity:	745 cc / 45.4 cu-in
Bore x Stroke:	77 x 80mm
Cooling System:	Liquid-cooled
Compression Ratio:	10.7:1
Emission:	EURO5
Induction:	PGM-FI electronic fuel injection
Ignition:	Computer-controlled digital transistorised with electronic advance
Starting:	Electric
Max Power:	43.1 kW / 57.8 hp @ 6750 rpm
Max Torque:	69 Nm / 50.9 lb-ft @ 4750 rpm
Clutch:	Wet multiplate hydraulic 2-clutch
Transmission:	6-Speed Dual Clutch Transmission
Final Drive:	Chain
Frame:	Steel Diamond
Front Suspension:	41 mm USD forks
Front Wheel Travel:	120 mm / 4.7 in
Rear Suspension:	Prolink with Rear Shock Preload adjustment
Rear Wheel Travel:	120 mm / 4.7 in
Front Brakes:	2x 296mm discs with 4-piston calipers
Rear Brakes:	Single 240mm disc with single-piston caliper
ABS:	2-channel ABS standard
Wheels:	Spoked
Front Rim:	17 x 3.50
Rear Rim:	15 x 4.50
Front Tyre:	120/70 R17
Rear Tyre:	160/60 R15
Rake:	27˚
Trail:	104 mm / 4.0 in
Dimensions:	Length 2215 mm / 87.2 in Width 940 mm / 37 in Height 1370 mm/ 53.9in
Wheelbase:	1590 mm / 62.6 in
Seat Height:	820 mm / 32.3 in
Ground Clearance:	165 mm / 6.4 in
Wet Weight:	236 kg / 520.2 lbs
Fuel Capacity:	13.2 Litres / 3.4 US gal
