Honda X-ADV (2017-18) technical specifications

Honda X-ADV technical specifications

Honda X-ADV is produced in 2017-18. Engine is Four stroke , Parallel twin, SOHC, 4 valves per cylinder, displacement 745 cc / 45.4 cu-in , produces power 40.3 kW / 54 hp @ 6250 rpm and 68 Nm / 50.8 lb-ft@ 4750 rpm. Honda X-ADV wet weight is 238 kg / 524.7 lbs. Honda X-ADV has 6 photos.

Technical specifications

+ Add to 'Compare list'
Model: X-ADV
Years: 2017-18
Engine: Four stroke , Parallel twin, SOHC, 4 valves per cylinder
Capacity: 745 cc / 45.4 cu-in
Bore x Stroke: 77 x 80mm
Cooling System: Liquid-cooled
Compression Ratio: 10.7:1
Induction: PGM-FI electronic fuel injection
Ignition: Computer-controlled digital transistorised with electronic advance
Starting: Electric
Max Power: 40.3 kW / 54 hp @ 6250 rpm
Max Torque: 68 Nm / 50.8 lb-ft@ 4750 rpm
Clutch: Wet Multiplate
Clutch DCT: Wet multiplate hydraulic 2-clutch
Transmission: 6 Speed Manual
Transmission DCT: 6-Speed Dual Clutch Transmission
Final Drive: Chain
Frame: Steel Diamond
Front Suspension: 41 mm telescopic forks
Rear Suspension: Prolink with Rear Shock Preload adjustment
Front Brakes: Single 320 mm wavy hydraulic disc 2 piston calipers and sintered metal pads
Rear Brakes: Single 240 mm wavy hydraulic disc 1 piston caliper and sintered metal pads
ABS: 2-channel ABS standard
Front Tyre: 120/70 R17
Rear Tyre: 160/60 R15
Rake: 27˚
Trail: 104 mm / 4.1 in
Dimensions: Length 2245 mm / 88.4 in Width 910 mm / 35.8 in Height 1375 mm/ 54.1 in
Wheelbase: 1590 mm / 62.6 in
Seat Height: 820 mm / 32.3 in
Ground Clearance: 162 mm / 6.4 in
Wet Weight: 238 kg / 524.7 lbs
Fuel Capacity: 13 Litres / 3.4 US gal
