Honda VT 1100C3 Shadow Aero (2000-02) technical specifications

Honda VT 1100C3 Shadow Aero technical specifications

Honda VT 1100C3 Shadow Aero is produced in 2000-02. Engine is Four stroke, 45°V-Twin, OHC, 3 valves per cylinder., displacement 1099 cc / 67.1 cub in. , produces power 67 hp / 49 kW @ 5500 rpm and 91 Nm / 9.27 kgf-m / 67 lb-ft. @ 2700 rpm. Honda VT 1100C3 Shadow Aero weighs 279 kg / 615 lbs. Honda VT 1100C3 Shadow Aero has 6 photos.

Technical specifications

+ Add to 'Compare list'
Model: VT 1100C3 Shadow Aero
Years: 2000-02
Engine: Four stroke, 45°V-Twin, OHC, 3 valves per cylinder.
Capacity: 1099 cc / 67.1 cub in.
Bore x Stroke: 87.5 x 91.4 mm
Compression Ratio: 8.5:1
Cooling System: Liquid cooled
Oil Capacity: 3.8 L / 4 US quarts
Induction: 2 x 36 mm Keihin CV carburetors
Ignition: CDI
Battery: 12v, 16 AH
Starting: Electric
Max Power: 67 hp / 49 kW @ 5500 rpm
Max Torque: 91 Nm / 9.27 kgf-m / 67 lb-ft. @ 2700 rpm
Transmission: 5 Speed
Final Drive: Shaft, 3.091:1
Front Suspension: 41mm stanchions
Front Wheel Travel: 150 mm / 5.9 in
Rear Suspension: Dual shocks with 5 way spring preload adjustment
Rear Wheel Travel: 98 mm / 3.7 in
Front Brakes: Single 315mm disc 2 piston caliper
Rear Brakes: Single 256mm disc 1 piston caliper
Front Wheels: Wire spoke, 17 x 3.00
Rear Wheels: Wire spoke, 15 x 3.50
Front Tyre: 140/80-17
Rear Tyre: 170/80-15
Rake: 32.25°
Trail: 145 mm / 5.7 in
Lengtth: 2550 mm / 100.8 in
Wheelbase: 1680mm / 66.1 in
Seat Height: 725mm / 28.5 in
Dry Weight: 279 kg / 615 lbs
Wet Weight: 302 kg / 666 lbs
Fuel Capacity: 16.5 Litres / 4.4 US gal
Standing ¼ Mile: 14.7 sec / 87.5 mph
