Honda VFR 800X Crossrunner (ED-type) (2013) technical specifications

Honda VFR 800X Crossrunner (ED-type) technical specifications

Honda VFR 800X Crossrunner (ED-type) is produced in 2013. Engine is Four stroke, 90° V-4, SOHC, 4 valve per cylinder, displacement 782 cc / 47.7 cu-in , produces power 74.9 kW / 100.6 hp @ 10000 rpm and 72.8 Nm / 7.34 kg-m @ 9500 rpm. Honda VFR 800X Crossrunner (ED-type) wet weight is 240 kg / 529 lbs. Honda VFR 800X Crossrunner (ED-type) has 6 photos.

Technical specifications

+ Add to 'Compare list'
Model: VFR 800X Crossrunner (ED-type)
Years: 2013
Engine: Four stroke, 90° V-4, SOHC, 4 valve per cylinder
Capacity: 782 cc / 47.7 cu-in
Bore x Stroke: 72 x 48 mm
Compression Ratio: 11.6:1
Cooling System: Liquid cooled
Lubrication: Wet sump
Induction: PGM-FI electronic fuel injection, 35mm Throttle Bore
Ignition: Computer-controlled digital transistorised with electronic advance
Starting: Electric
Max Power: 74.9 kW / 100.6 hp @ 10000 rpm
Max Torque: 72.8 Nm / 7.34 kg-m @ 9500 rpm
Clutch: Wet, multiplate with coil springs
Transmission: 6 Speed
Final Drive: Chain
Gear Ratio: 1st 2.846 (37/13) 2nd 2.062 (33/16) 3rd 1.578 (30/19) 4th 1.291 (31/24) 5th1.111 (30/27) 6th 0.965 (28/29)
Frame: Aluminium, twin spar
Front Suspension: 43mm cartridge-type telescopic fork with stepless preload adjustment,
Front Wheel Travel: 108 mm / 4.2 in
Rear Suspension: Pro-Link with gas-charged HMAS damper, 7-step preload and stepless rebound damping adjustment,
Rear Wheel Travel: 119 mm / 4.7 in
Front Brakes: 2x Hydraulic discs 320mm floating, 6-piston radial calipers, Combined-ABS
Rear Brakes: Single hydraulic 276mm disc 2 piston caliper, Combined-ABS
Front Tyre: 120/70 Z R17
Rear Tyre: 180/55 R17
Rake: 25°
Trail: 96 mm / 3.7 in
Dimensions: Length 2130 mm / 83.8 in Width 799 mm / 31.4 in Height 1243 mm / 48.9 in
Wheel base: 1464 mm / 57.6 in
Seat Height: 816 mm / 32.1 in
Ground Clearance: 140 mm / 5.5 in
Wet Weight: 240 kg / 529 lbs
Fuel Capacity: 21.5 Litres / 5.6 gal
