Honda VFR 1200X Crosstourer (2012) technical specifications

Honda VFR 1200X Crosstourer technical specifications

Honda VFR 1200X Crosstourer is produced in 2012. Engine is Four stroke, 76 ° V-4, SOHC, 4 valve per cylinder, displacement 1237 cc / 69.2 cu-in , produces power 95 kW / 127 hp @ 7750 rpm and 126 Nm / 92.9 lb-ft @ 6500 rpm. Honda VFR 1200X Crosstourer wet weight is 275 kg / 610 lbs. Honda VFR 1200X Crosstourer has 4 photos.

Technical specifications

+ Add to 'Compare list'
Model: VFR 1200X Crosstourer
Years: 2012
Engine: Four stroke, 76 ° V-4, SOHC, 4 valve per cylinder
Capacity: 1237 cc / 69.2 cu-in
Bore x Stroke: 81 x 60 mm
Compression Ratio: 12.0:1
Cooling System: Liquid cooled
Induction: PGM-FI electronic fuel injection 44mm Throttle Bore
Ignition: Computer-controlled digital transistorised with electronic advance gnition Timing 8.4° BTDC (idle speed)
Spark Plug: NGK IMR8E-9HES
Starting: Electric
Max Power: 95 kW / 127 hp @ 7750 rpm
Max Torque: 126 Nm / 92.9 lb-ft @ 6500 rpm
Clutch: Wet, multiplate
Transmission: 6 Speed
Final Drive: Shaft
Gear Ratio: 1 2.600 (39T / 15T) *2.250 (36T / 16T) / 2 1.600 (32T / 20T) *1.700 (34T / 20T) / 3 1.260 (29T / 28T) *1.304 (30T / 23T) / 4 1.076 (28T / 26T) *1.107 (31T / 28T) / 5 0.961 (25T / 26T) *0.967 (29T / 30T) / 6 0.897 (35T / 39T) *0.886 (31T / 35T)
Final Reduction: 2.699 (37/39 x 19/17 x 28/11) * 2.706 (39/41 x 19/17 x 28/11)
Frame: Diamond; aluminium twin-spar
Front Suspension: I43mm inverted telescopic forks with hydraulic damping, preload and rebound damping adjustment,
Rear Suspension: Pro-Link with gas-charged damper, preload and stepless rebound damping adjustment
Front Brakes: 2x 310mm discs ABS
Rear Brakes: Single 276mm disc ABS
Front Tyre: 110/80-R19
Rear Tyre: 150/70 R17
Rake: 28.0°
Trail: 107 mm / 4.2 in
Dimensions: Length 2285 mm / 90.0 in Width 915 mm . / 36.0 in Height 1335 mm / 52.6 in
Wheel base: 1595 mm / 62.8 in
Seat Height: 850 mm / 33.5 in
Ground clearance: 180 mm / 7.1 in
Wet Weight: 275 kg / 610 lbs
Fuel Capacity: 21 Litres / 5.6 US gal
