Honda VFR 1200FA / DCT (2017) technical specifications

Honda VFR 1200FA / DCT technical specifications

Honda VFR 1200FA / DCT is produced in 2017. Engine is Four stroke, 76 ° V-4, SOHC, 4 valve per cylinder, displacement 1237 cc / 75.4 cu-in cc / 75.4 cu-in , produces power 127 kW / 170 hp @ 10000 rpm and 129 Nm / 95.1 lb-ft @ 8750 rpm. Honda VFR 1200FA / DCT top speed is 251.2 km/h / 156 mph. Honda VFR 1200FA / DCT wet weight is 267 kg / 613 lbs. Honda VFR 1200FA / DCT has 4 photos.

Technical specifications

+ Add to 'Compare list'
Model: VFR 1200FA / DCT
Years: 2017
Engine: Four stroke, 76 ° V-4, SOHC, 4 valve per cylinder
Capacity: 1237 cc / 75.4 cu-in cc / 75.4 cu-in
Bore x Stroke: 81 x 60 mm
Compression Ratio: 12.0:1
Cooling System: Liquid cooled
Induction: PGM-FI electronic injection
Ignition: Digital transistorized with electronic advance computerized control Ignition Timing: 6.4 ° -10.4 ° BTDC (idle speed) Sparkplug Type: IMR9E-9HES (NGK); VUH27ES (DENSO)
Spark Plug: IMR9E-9HES (NGK); VUH27ES (DENSO)
Starting: Electric
Max Power: 127 kW / 170 hp @ 10000 rpm
Max Torque: 129 Nm / 95.1 lb-ft @ 8750 rpm
Clutch: Wet, multiplate slipper type, Clutch Operation Hydraulic
Transmission: 6 speed with two automatic modes and manual mode
Final Drive: Shaft
Gear Ratio: 1 2.600 (39/15) 2nd 1.736 (33/19) 3rd 1.363 (30/22) 4th 1.160 (29/25) 5th 1.032 (32/31) 6th 0.939 (31/33)
Chassis Type: Double beam cast aluminum vacuum mold Geometry direction: 25.5 degrees, 101 mm forward Swingarm: single-arm aluminum driveshaft
Front Suspension: Inverted telescopic fork 41 mm HMAS cartridge-type with adjustable spring preload without positions,
Front Wheel Travel: 120 mm / 4.3 in
Rear Suspension: Pro-Link HMAS gas shock, adjustable spring preload 25 positions,
Rear Wheel Travel: 120 mm / 4.3 in
Front Brakes: 2x Hydraulic discs 320mm floating, 6-piston radial calipers, Combined-ABS
Rear Brakes: Single hydraulic 276mm disc 2 piston caliper, Combined-ABS
Front Tyre: 120/70 ZR17M / C (58W)
Rear Tyre: 190/55 ZR17M / C (75W)
Rake (Caster angle): 25.3°
Trail: 101.mm / 4 in
Dimensions: Length 2244 mm / 88.3 in Width 752 mm / 29.6 in Height 1222 mm / 48.1 in
Wheelbase: 1545 mm / 60.8 in
Seat Height: 815 mm / 31.9 in
Wet Weight: 267 kg / 613 lbs
Fuel Capacity: 18.5 Litres / 5.0 US gal
Average Consumption: 17.8 km/lit
Standing ¼ Mile: 10.8 sec
Top Speed: 251.2 km/h / 156 mph
