Honda ST 1300 Pan European (2014) technical specifications

Honda ST 1300 Pan European technical specifications

Honda ST 1300 Pan European is produced in 2014. Engine is Four stroke, longitudinally 90°V-four cylinder, DOHC, 4 valve per cylinder, displacement 1261 cc / 76.9 cu-in , produces power 118 hp / 87 kW @ 8000 rpm and 117 Nm / 11.93 kg-m @ 6500 rpm. Honda ST 1300 Pan European top speed is 225 km/h / 139.8 mph. Honda ST 1300 Pan European weighs 286 kg / 631 lbs - ABS 289 kg / 637 lbs. Honda ST 1300 Pan European has 3 photos.

Technical specifications

+ Add to 'Compare list'
Model: ST 1300 Pan European
Years: 2014
Engine: Four stroke, longitudinally 90°V-four cylinder, DOHC, 4 valve per cylinder
Capacity: 1261 cc / 76.9 cu-in
Bore x Stroke: 78 x 66 mm
Compression Ratio: 10.8:1
Cooling System: Liquid cooled
Lubrication: Wet sump
Engine Oil: Semi-Synthetic,10W/40
Induction: PGM-FI electronic fuel injection, 36 mm throttle bodies
Ignition: Computer-controlled digital transistorized
Spark Plug: NGK, CR7EH-9
Starting: Electric
Max Power: 118 hp / 87 kW @ 8000 rpm
Max Torque: 117 Nm / 11.93 kg-m @ 6500 rpm
Clutch: Wet, multiple discs, cable operated
Transmission: 5 Speed
Final Drive: Shaft
Frame: Aluminum-alloy triple-box-section pressure cast dual-spar with cast aluminum-alloy swingarm
Front Suspension: 45mm air-assist telescopic fork
Front Wheel Travel: 117 mm / 4.3 in
Rear Suspension: Single-side conventional damper with adjustable preload and rebound damping
Rear Wheel Travel: 133 mm / 4.8 in
Front Brakes: 2x 310 mm discs 3 piston calipers
Rear Brakes: Single 316 mm disc 3 piston caliper (ABS option available)
Front Tyre: 120/70 ZR18
Rear Tyre: 170/60 ZR17
Rake: 26°
Trail: 98 mm / 3.9 in
Dimensions: Length 2282 mm / 89.8 in Width 935 mm / 36.8 in - including panniers Height 1332 mm / 52.4 in
Wheelbase: 1491 mm / 58.7 in
Seat Height: 790 mm / 31.1 in
Dry Weight: 286 kg / 631 lbs - ABS 289 kg / 637 lbs
Wet Weight: 331 kg / 730 lbs
Fuel Capacity: 29 Liters / 7.7 US gal
Consumption Average: 19.8 km/lit / 46.7 mp/g
Standing ¼ Mile: 11.6 sec
Top Speed: 225 km/h / 139.8 mph
