Honda NC 750X / DCT (2014-15) technical specifications

Honda NC 750X / DCT technical specifications

Honda NC 750X / DCT is produced in 2014-15. Engine is Four stroke , Parallel twin, SOHC, 4 valves per cylinder, displacement 745 cc / 45.4 cu-in , produces power 40.3 kW / 54 hp @ 6250 rpm and 68 Nm / 50.8 lb-ft@ 4750 rpm. Honda NC 750X / DCT wet weight is 218 kg / 480.6 in. Honda NC 750X / DCT has 7 photos.

Technical specifications

+ Add to 'Compare list'
Model: NC 750X / DCT
Years: 2014-15
Engine: Four stroke , Parallel twin, SOHC, 4 valves per cylinder
Capacity: 745 cc / 45.4 cu-in
Bore x Stroke: 77 x 80mm
Cooling System: Liquid-cooled
Compression Ratio: 10.7:1
Induction: PGM-FI electronic fuel injection
Ignition: Computer-controlled digital transistorised with electronic advance
Starting: Electric
Max Power: 40.3 kW / 54 hp @ 6250 rpm
Max Torque: 68 Nm / 50.8 lb-ft@ 4750 rpm
Clutch: Wet Multiplate
Clutch DCT: Wet multiplate hydraulic 2-clutch
Transmission: 6 Speed Manual
Transmission DCT: 6-Speed Dual Clutch Transmission
Final Drive: Chain
Gear Ratio: 1 2.812 (DCT 2.666) 2 1.894 (DCT 1.904) 3 1.454 (DCT 1.454) 4 1.200 (DCT 1.200) 5 1.033 (DCT 1.033) 6 0.837 (DCT 0.837)
Final Reduction: 2.687 (DCT 2.437)
Frame: Rigid tube steel diamond
Front Suspension: 41 mm telescopic forks
Front Wheel Travel: 153 mm / 6.0 in
Rear Suspension: Single monoshock damper
Rear Wheel Travel: 150 mm / 5.9 in
Front Brakes: Single 320 mm hydraulic disc 3 piston calipers and sintered metal pads
Rear Brakes: Single 240 mm hydraulic disc 1 piston caliper and sintered metal pads
Front Tyre: 120/70-ZR17
Rear Tyre: 160/60-ZR17
Rake: 27˚
Trail: 110 mm / 4.3 IN
Dimensions: Length 2210 mm / 87.0 in Wedth 830 mm / 32.7 in Height 1285 mm / 50.6 in
Wheelbase: 1540 mm / 60.6 in
Seat Height: 790 mm (Europe) - 775 mm (Japan)
Ground Clearance: 165 mm / 6.5 in
Wet Weight: 218 kg / 480.6 in
Fuel Capacity: 14.1 Litres / 3.7 US gal
