Honda CRF 250L / ABS (2017-18) technical specifications

Honda CRF 250L / ABS technical specifications

Honda CRF 250L / ABS is produced in 2017-18. Engine is Four stroke single cylinder, DOHC, 4 valves, displacement 249 cc / 15.28 cu-in , produces power 17 kW / 23 hp @ 8500 rpm and 22 Nm / 2.24 kg-m @ 7000 rpm. Honda CRF 250L / ABS wet weight is 147 kg / 322 lbs. Honda CRF 250L / ABS has 5 photos.

Technical specifications

+ Add to 'Compare list'
Model: CRF 250L / ABS
Years: 2017-18
Engine: Four stroke single cylinder, DOHC, 4 valves
Capacity: 249 cc / 15.28 cu-in
Bore x Stroke: 76 ×55 mm
Cooling System: Liquid cooled
Compression Ratio: 10.7:1
Lubrication: Wet sump
Induction: Keihin 37mm flat-slide with throttle position sensor (TPS)
Ignition: Full-transistor battery ignition
Starting: Electric
Max Power: 17 kW / 23 hp @ 8500 rpm
Max Torque: 22 Nm / 2.24 kg-m @ 7000 rpm
Clutch: Wet multiplate with coil springs
Transmission: 6 Speed
Final Drive: #520 chain; 14T/40T
Gear Ratio: 1st 3.333 2nd 2.117 3rd 1.571 4th 1.304 5th 1.115 6th 0.962
Frame: Semi-double cradle
Front Suspension: 43mm inverted fork;
Front Wheel Travel: 221 mm / 8.7 in
Rear Suspension: Pro-Link® single shock with spring
Rear Wheel Travel: 239 mm / 9.4 in
Front Brakes: Single 256mm disc 2 piston caliper, ABS
Rear Brakes: Single 220mm disc 1 piston caliper, ABS
Front Tyre: 3.00-21
Rear Tyre: 120/80-18
Rake: 27°
Trail: 112 mm / 4.4 in
Dimensions: Length 2195 mm / 86.4 in Width 815 mm / 32.0 in Height 1195 mm / 47.0 in
Wheelbase: 1445 mm / 56.9 in
Seat Height: 875 mm / 34.4 in
Wet Weight: 147 kg / 322 lbs
Fuel Capacity: 7.7 Litres / 2.0 US gal
