Honda CBR 600RR (2005) technical specifications

Honda CBR 600RR technical specifications

Honda CBR 600RR is produced in 2005. Engine is Four stroke, transverse four cylinder, DOHC, 4 valve per cylinder., displacement 599 cc / 36.5 cu-in , produces power 117 hp / 87.2 kW @ 13000 rpm and 66 Nm / 48.7 lb-ft @ 11000 rpm. Honda CBR 600RR top speed is 255.9 km/h. Honda CBR 600RR weighs 163.7 kg / 361 lbs. Honda CBR 600RR has 6 photos.

Technical specifications

+ Add to 'Compare list'
Model: CBR 600RR
Years: 2005
Engine: Four stroke, transverse four cylinder, DOHC, 4 valve per cylinder.
Capacity: 599 cc / 36.5 cu-in
Bore x Stroke: 67 x 42.5 mm
Compression Ratio: 12.0:1
Cooling System: Liquid cooled
Lubrication: Wet sump
Engine Oil: Synthetic, 10W/40
Induction: Dual Stage Fuel Injection (DSFI)
Ignition: Computer-controlled digital transistorized with three-dimensional mapping
Spark Plug: NGK, IMR9C-9H
Starting: Electric
Max Power: 117 hp / 87.2 kW @ 13000 rpm
Power Rear Tyre: 102 hp @ 13500 rpm
Max Torque: 66 Nm / 48.7 lb-ft @ 11000 rpm
Transmission: 6 Speed
Final Drive: Chain
Frame: Aluminium, twin spar
Front Suspension: 41mm inverted HMAS cartridge fork with spring preload, rebound and compression damping adjustability.
Front Wheel Travel: 119.5 mm / 4.3 in
Rear Suspension: Unit Pro-Link HMAS single shock with spring preload, rebound and compression damping adjustability.
Rear Wheel Travel: 129.5 mm / 5.1 in
Front Brakes: 2x 310mm discs 4 piston calipers
Rear Brakes: Single 220mm disc 1 piston caliper
Front Tyre: 120/70 ZR17
Rear Tyre: 180/55 ZR17
Turning Radius: 10.5 feet
Rake (Caster Angle): 24°
Trail: 95 mm / 3.7 in
Dimensions: Length 2065 mm / 81.2 in Width 685 mm / 26.9 in Height 1135 mm / 44.6 in
Wheelbase: 1389.3 mm / 54.7 in
Seat Height: 820 mm / 32.3
Dry Weight: 163.7 kg / 361 lbs
Wet Weigh: 191 kg / 421 lbs
Fuel Capacity: 18 Liters
Standing ¼ Mile: 10.71 sec / 134.9 mp/h
Standing 60mph: 3.13 sec
Standing 140mph: 13.39 sec
Top Speed: 255.9 km/h
