Honda CBR 500R (2017-18) technical specifications

Honda CBR 500R technical specifications

Honda CBR 500R is produced in 2017-18. Engine is Four stroke, parallel-twin, DOHC; 4 valves per cylinder, displacement 471 cc / 28.7 cu-in , produces power 46.9 hp / 35 kW @ 8500 rpm and 43 Nm / 31.7 lb-ft @ 7000 rpm. Honda CBR 500R wet weight is 191 kg / 423 lbs. Honda CBR 500R has 3 photos.

Technical specifications

+ Add to 'Compare list'
Model: CBR 500R
Years: 2017-18
Engine: Four stroke, parallel-twin, DOHC; 4 valves per cylinder
Capacity: 471 cc / 28.7 cu-in
Bore x Stroke: 67.0 x 66.8 mm
Compression Ratio: 10.7:1
Cooling System: Liquid cooled
Induction: PGM-FI with 34mm throttle bodies
Ignition: Computer-controlled digital transistorized with electronic advance
Starting: Electric
Max Power: 46.9 hp / 35 kW @ 8500 rpm
Max Power Rear Wheel: 42.9 hp / 31.9 kW @ 8500 rpm
Max Torque: 43 Nm / 31.7 lb-ft @ 7000 rpm
Transmission: 6 Speed
Final Drive: O-ring-sealed chain
Frame: Back Bone
Front Suspension: 41mm Telescopic fork
Front Wheel Travel: 109 mm / 4.3 in
Rear Suspension: Pro-Link® single shock with nine-position spring preload adjustability
Rear Wheel Travel: 120 mm / 4.7 in
Front Brakes: Single 320mm wave disc 2 piston calipers
Rear Brakes: Single 240mm wave disc 1 piston calipers
Front Tyre: 120/70-17
Rear Tyre: 160/60-17
Rake (Caster Angle): 25.5°
Trail: 103mm / 4.05 in
Wheelbase: 1400 mm / 55.5 in
Seat Height: 780 mm / 30.7 in
Wet Weight: 191 kg / 423 lbs
Fuel Capacity: 16.6 Liters / 4.4 US gal
