Honda CBR 250R (2011-12) technical specifications

Honda CBR 250R is produced in 2011-12. Engine is Four stroke, single cylinder, DOHC, 4 valve per cylinder., displacement 249.4 cc / 15.2 cu-in , produces power 23.7 hp / 17.7 kW @ 9900 rpm and 14.6 lb-ft / 19.86 Nm @ 6750 rpm. Honda CBR 250R wet weight is 162 kg / 356 lbs. Honda CBR 250R has 9 photos.

Technical specifications

+ Add to 'Compare list'

Model:	CBR 250R
Years:	2011-12
Engine:	Four stroke, single cylinder, DOHC, 4 valve per cylinder.
Capacity:	249.4 cc / 15.2 cu-in
Bore x Stroke:	76 x 55mm
Cooling System:	Liquid cooled
Compression Ratio:	10.7: 1
Induction:	Electronic fuel injection PGM-F
Ignition:	Computer-controlled digital transistor with electronic advance
Starting:	Electric
Max Power:	23.7 hp / 17.7 kW @ 9900 rpm
Max Torque:	14.6 lb-ft / 19.86 Nm @ 6750 rpm
Clutch:	Wet multiplate hydraulic clutch
Transmission:	6 Speed
Final Drive:	#520 O-ring-sealed chain
Frame:	Diamond; steel twin-spar
Front Suspension:	37mm telescopic fork,
Front Wheel Travel:	130 mm / 5.1 in
Rear Suspension:	Pro-Link Monoshock damper,
Rear Wheel Travel:	103 mm / 4.07 in
Front Brakes:	Single 296mm disc 2 piston caliper
Rear Brakes:	Single 220mm disc 1 piston caliper
Front Tyre:	110/70-MC17
Rear Tyre:	140/70-MC17
Rake:	25°
Trail:	98.6 mm / 3.9 in
Dimensions:	Length 2035 mm / 80.1 in Width 720 mm / 28 in Height 1125 mm / 44.3 in
Wheelbase:	1370 mm / 53.9 in
Seat Height:	785 mm / 30.5 in
Wet Weight:	162 kg / 356 lbs
Wet Weight ABS:	166 kg / 366 lbs ABS
Fuel Capacity:	13 Liters / 3.4 gal
