Honda CBR 125R (2016-17) technical specifications

Honda CBR 125R technical specifications

Honda CBR 125R is produced in 2016-17. Engine is Four stroke single cylinder, SOHC, 2 valve., displacement 124.7 cc / 7.6 cu-in , produces power 13.6 hp / 10 kW @ 10000 rpm and 10.6 Nm / 1.08 kg-m @ 8250 rpm. Honda CBR 125R wet weight is 137 kg / 302 lbs. Honda CBR 125R has 6 photos.

Technical specifications

+ Add to 'Compare list'
Model: CBR 125R
Years: 2016-17
Engine: Four stroke single cylinder, SOHC, 2 valve.
Capacity: 124.7 cc / 7.6 cu-in
Bore x Stroke: 58 x 47.2 mm
Cooling System: Liquid cooled
Compression Ratio: 11.0:1
Lubrication: Wet sump
Induction: PGM-FI electronic fuel injection
Ignition: Fully transistorised with electronic advance
Starting: Electric
Max Power: 13.6 hp / 10 kW @ 10000 rpm
Max Torque: 10.6 Nm / 1.08 kg-m @ 8250 rpm
Clutch: Wet, multiple discs, cable operated
Transmission: 6 Speed
Final Drive: Chain
Frame: Steel, Double cradle frame
Front Suspension: 31mm telescopic fork,
Front Wheel Travel: 109 mm / 4.2 in
Rear Suspension: Monoshock damper,
Rear Wheel Travel: 120 mm / 4.7 in
Front Brakes: Single 276mm disc 2 piston caliper
Rear Brakes: Single 220mm disc 1 piston caliper
Front Tyre: 100/80 –17
Rear Tyre: 130/70 –17
Rake: 25°
Trail: 88 mm / 3.4 in
Dimensions: Length 1946 mm / 76.6 in Width 704 mm / 27.7 in Height 1089 mm / 42.9 in
Wheelbase: 1310 mm / 50.9 in
Seat Height: 795 mm / 31.3 in
Ground Clearance: 185 mm / 7.3 in
Wet Weight: 137 kg / 302 lbs
Fuel Capacity: 13 Litres / 2.9 US gal
