Honda CBR 1100XX Super Blackbird (2002) technical specifications

Honda CBR 1100XX Super Blackbird technical specifications

Honda CBR 1100XX Super Blackbird is produced in 2002. Engine is Four stroke, transverse four cylinder, DOHC, 4 valve per cylinder., displacement 1137 cc / 69.3 cu-in , produces power 164 hp / 112 kW @ 10000 rpm and 124 Nm / 12.6 kg-fm 91.5 ft.lb @ 7250 rpm. Honda CBR 1100XX Super Blackbird top speed is 303 km/h / 188.2 mph. Honda CBR 1100XX Super Blackbird weighs 223 kg / 490 lbs. Honda CBR 1100XX Super Blackbird has 4 photos.

Technical specifications

+ Add to 'Compare list'
Model: CBR 1100XX Super Blackbird
Years: 2002
Engine: Four stroke, transverse four cylinder, DOHC, 4 valve per cylinder.
Capacity: 1137 cc / 69.3 cu-in
Bore x Stroke: 79 x 58 mm
Cooling System: Liquid cooled
Compression Ratio: 11.0:1
Lubrication: Wet sump
Engine Oil: Synthetic, 10W/40
Oil Capacity: 4.6 Liters / 4.9 quarts
Exhaust: System Layout 4-1-2 into 2 (all models) 4-1-2 into 2 with 3 catalytic converters (2001
Induction: Keihin Electronic Fuel Injection 42 mm Throttle Body
Ignition : Computer-controlled digital transistorized
Spark Plug: NGK, CR9EHVX-9
Starting: Electric
Max Power: 164 hp / 112 kW @ 10000 rpm
Max Power Rear Tyre: 141.4 hp @ 10100 rpm
Max Torque: 124 Nm / 12.6 kg-fm 91.5 ft.lb @ 7250 rpm
Engine Redline: 11800 rpm
Clutch: Hydraulic wet multi plate
Transmission : 6 Speed
Final Drive: ‘O’ or ‘X’ ring Chain
Primary Drive Gear Teeth Ratio: 56/ 88 (1.571:1)
Final Drive Sprocket Teeth Ratio: 17/ 45 (2.647:1)
Gear Ratio: 6th 25/ 24 (1.042:1) 5th 28/ 24 (1.167:1) 4th 28/ 21 (1.333:1) 3rd 30/ 19 (1.579:1) 2nd 32/ 16 (2.000:1) 1st 36/ 13 (2.769:1)
Frame: Aluminium twin spar
Front Suspension: 43mm H.M.A.S. Cartridge-type fork,
Front Wheel Travel: 120 mm / 4.7 in
Rear Suspension: Pro-Link single shock with spring preload and rebound damping adjustability,
Rear Wheel Travel: 120 mm / 4.7 in
Front Brakes: 2x 310mm discs 3 piston calipers
Rear Brakes: Single 256mm disc 3 piston caliper
Front Tyre: 120/70 ZR17
Rear Tyre: 180/55 ZR17
Rake: 25°
Trail: 99 mm / 3.8 in
Dimensions: Length 2,160mm / 85.0in Width 720mm / 28.4in Height 1,170m / 46.1in
Wheelbase: 1490 mm / 58.6 in
Seat Height: 810 mm / 31.9 in
Ground Clearance: 130 mm / 5.1 in
Dry Weight: 223 kg / 490 lbs
Wet Weight: 254 kg / 559 lbs
Fuel Capacity : 24 Litres / 5.2 gal
Consumption Average: 16.5 km/lit
Braking 60 - 0 / 100 - 0: 12.2 m / 37.8 m
0-100 km/h: 2.4 sec
0-140 km/h: 4.6 sec
0-200 km/h: 9.2 sec
Acceleration in 3rd gear (6th gear)100-160 km/h: 3,2 (6,7) sec
Standing ¼ Mile : 10.0 sec / 214 km/h
Top Speed: 303 km/h / 188.2 mph
