Technical specifications
|
| Model: |
CBR 1000F |
| Years: |
1988 |
|
Engine:
|
Four stroke, transverse four cylinder, DOHC, 4 valve per cylinder.
|
|
Capacity:
|
998 cc / 60.9 cu-in
|
|
Bore x Stroke:
|
77 x 53.6 mm
|
|
Cooling System:
|
Liquid cooled,
|
|
Compression Ratio:
|
10.5:1
|
|
Induction:
|
4x 38mm Keihin carburetors
|
|
Ignition:
|
CDI
|
|
Starting:
|
Electric
|
|
Max Power:
|
132 hp / 96.2 kW @ 9500 rpm
|
|
Max Torque:
|
104 Nm / 76.7 lb-ft @ 8500 rpm
|
|
Clutch:
|
Wet, multiple discs, cable operated
|
|
Transmission:
|
6 Speed
|
|
Final Drive:
|
Chain
|
|
Frame:
|
Steel, Single cradle frame
|
|
Front Suspension:
|
Telescopic air assisted and ant-dive.
|
|
Rear Suspension:
|
Pro-link monoshock. 6-way preload. 3-way rebound damping adjust
|
|
Front Brakes:
|
2x 296mm discs 2 piston calipers
|
|
Rear Brakes:
|
Single 276mm disc 2 piston caliper
|
|
Front Tyre:
|
110/80-17
|
|
Rear Tyre:
|
140/80-17
|
|
Rake:
|
28°
|
|
Trail:
|
117 mm / 4.6 in
|
|
Wheelbase:
|
1505 mm / 59.3 in
|
|
Seat Height:
|
775 mm / 30.5 in
|
|
Dry Weight:
|
222 kg / 489.4 lbs
|
|
Fuel Capacity:
|
21 Litres / 5.5 gal
|
|
Consumption Average:
|
15.6 km/lit
|
|
Standing ¼ Mile:
|
11.0 sec
|
|
Top Speed:
|
258 km/h / 160.3 mph
|
|
Road Test:
|
Motosprint 1987 Group Test
|
