Honda CB 650F (2017) technical specifications

Honda CB 650F technical specifications

Honda CB 650F is produced in 2017. Engine is Four stroke, transverse four cylinder, DOHC, 4 valves per cylinder., displacement 649 cc / 39.6 cu-in , produces power 89.8 hp / 67.0 kW @ 11000 rpm and 46.4 lb-ft / 62.9 Nm @ 8000 rpm. Honda CB 650F wet weight is 209 kg / 461 lbs. Honda CB 650F has 6 photos.

Technical specifications

+ Add to 'Compare list'
Model: CB 650F
Years: 2017
Engine: Four stroke, transverse four cylinder, DOHC, 4 valves per cylinder.
Capacity: 649 cc / 39.6 cu-in
Bore x Stroke: 67 x 46 mm
Cooling System: Liquid cooled.
Compression Ratio: 11.4:1
Induction: PGM-FI Programmed Automatic Enrichment Circuit, with 32mm Throttle Bodies
Ignition: Digital transistorized with electronic advance
Starting: Electric
Max Power: 89.8 hp / 67.0 kW @ 11000 rpm
Max Torque: 46.4 lb-ft / 62.9 Nm @ 8000 rpm
Clutch: Wet, multiplate with coil springs
Transmission: 6 Speed
Final Drive: #525 O-ring sealed chain
Frame: Steel diamond twin spar
Front Suspension: 41mm telescopic forks
Front Wheel Travel: 110 mm / 4.3 in
Rear Suspension: Monoshock with spring-preload adjustability
Rear Wheel Travel: 128 mm / 5.0 in
Front Brakes: 2x 320mm hydraulic discs with dual piston calipers
Rear Brakes: Single 240mm disc with single piston caliper
Front Tyre: 120/70-ZR17
Rear Tyre: 180/55-ZR17
Rake: 25.3°
Trail: 101 mm / 4.0 in
Wheelbase: 1450 mm / 57.1 in
Seat Height: 810 mm / 31.9 in
Ground Clearance: 150 mm / 5.1 in
Wet Weight: 209 kg / 461 lbs
Fuel Capacity: 17.3 Litres / 4.5 US gal
