Honda CB 650 (1980) technical specifications

Honda CB 650 technical specifications

Honda CB 650 is produced in 1980. Engine is Four stroke, transverse four cylinder, SOHC, 2 valves per cylinder., displacement 626.8 cc / 38.2 cu-in , produces power 63 hp / 46.9 kW @ 9000 rpm and 51.5 Nm / 38 ft-lb @ 8000 rpm. Honda CB 650 top speed is 190 km/h. Honda CB 650 wet weight is 212 kg / 467.3 lbs. Honda CB 650 has 3 photos.

Technical specifications

+ Add to 'Compare list'
Model: CB 650
Years: 1980
Engine: Four stroke, transverse four cylinder, SOHC, 2 valves per cylinder.
Capacity: 626.8 cc / 38.2 cu-in
Bore x Stroke: 59.8 x 55.8 mm
Cooling System: Air cooled.
Compression Ratio: 9.0:1
Induction: 4x 26mm Keihin carburetors
Ignition: Transistorized
Starting: Electric
Max Power: 63 hp / 46.9 kW @ 9000 rpm
Max Torque: 51.5 Nm / 38 ft-lb @ 8000 rpm
Transmission: 5 Speed
Final Drive: Chain
Front Suspension: Centre axle coil spring forks
Front Wheel Travel: 135 mm / 5.3 in
Rear Suspension: Dual Showa dampers. adjustable spring preload.
Rear Wheel Travel: 91 mm / 3.5 in
Front Brakes: Single 275mm discs 1 piston calipers
Rear Brakes: 180mm Drum
Front Tyre: 3.50-19
Rear Tyre: 4.50-17
Wet Weight: 212 kg / 467.3 lbs
Fuel Capacity: 18 Litres / 4.7 US gal
Consumption Average: 41.1 mpg
Standing ¼ Mile: 13.4 sec / 157.7 km/h
Top Speed: 190 km/h
