Honda CB 600F Hornet (2002-03) technical specifications

Honda CB 600F Hornet technical specifications

Honda CB 600F Hornet is produced in 2002-03. Engine is Four stroke, transverse four cylinder, DOHC, 4 valves per cylinder, displacement 599 cc / 36.5 cu-in , produces power 97.5 hp / 71.1 kW @ 12000 rpm and 65.6 Nm / 6.83 kg-m @ 10000 rpm. Honda CB 600F Hornet top speed is 226.6 km/h. Honda CB 600F Hornet weighs 176 kg / 388.0 lbs. Honda CB 600F Hornet has 2 photos.

Technical specifications

+ Add to 'Compare list'
Model: CB 600F Hornet
Years: 2002-03
Engine: Four stroke, transverse four cylinder, DOHC, 4 valves per cylinder
Capacity: 599 cc / 36.5 cu-in
Bore x Stroke: 65 x 45.2 mm
Cooling System: Liquid cooled,
Compression Ratio: 12.0:1
Lubrication: Wet sump
Engine Oil: Semi-Synthetic, 10W/40
Induction: 4x 34mm carburetors
Ignition: Analogue CDI (Capacitive Discharge Ign.)
Spark Plug: NGK, CR9EH-9
Starting: Electric
Max Power: 97.5 hp / 71.1 kW @ 12000 rpm
Max Power Rear Tyre: 84.3 hp / 62.8 kW @ 11400 rpm
Max Torque: 65.6 Nm / 6.83 kg-m @ 10000 rpm
Clutch: Wet, multiple discs, cable operated
Transmission: 6 Speed
Final Drive: Chain
Frame: Steel, Backbone frame
Front Suspension: 41mm Telescopic forks
Front Wheel Travel: 120 mm / 4.7 in
Rear Suspension: Monoshock preload adjustable.
Rear Wheel Travel: 128 mm / 4.9 in
Front Brakes: 2x 296mm discs 2 piston calipers
Rear Brakes: Single 220mm disc 1 piston caliper
Front Tyre: 120/70-17
Rear Tyre: 180/55-17
Rake: 26°
Trail: 96 mm / 3.7 in
Dimensions: Length 2055 mm / 80.9 in Width 745 mm / 29.3 in Height 1070 mm / 42.1 in
Wheelbase: 1425 mm / 55.9 in
Seat Height: 790 mm / 31.1 in
Ground Clearance:: 140 mm / 5.5 in
Dry Weight: 176 kg / 388.0 lbs
Wet Weight: 198 kg / 456.5 lbs
Fuel Capacity: 16 Litres / 3.6 gal
Consumption Average: 17 km/lit
Braking 60 - 0 / 100 - 0: 13.3 m / 38.3 m
Standing ¼ Mile: 11.4 sec /192.2 km/h
Top Speed: 226.6 km/h
