Honda CB 1100EX (2017) technical specifications

Honda CB 1100EX technical specifications

Honda CB 1100EX is produced in 2017. Engine is Four stroke, transverse four cylinder, DOHC, 4 valve per cylinder., displacement 1140 cc/ 69.5 cu-in , produces power 66 kW / 88.5 hp @ 7500 rpm and 93 Nm / 68.5 lb-ft @ 5000 rpm. Honda CB 1100EX wet weight is 245 kg / 540 lbs. Honda CB 1100EX has 5 photos.

Technical specifications

+ Add to 'Compare list'
Model: CB 1100EX
Years: 2017
Engine: Four stroke, transverse four cylinder, DOHC, 4 valve per cylinder.
Capacity: 1140 cc/ 69.5 cu-in
Bore x Stroke: 73.5 x 67.2 mm
Cooling System: Air cooled
Compression Ratio: 9.5:1
Induction: PGM-FI electronic fuel injection Throttle Bore 32mm
Lubrication: Wet sump
Oil capacity: 4.9 Litres
Ignition: Full-transistor battery ignition / electric
Spark Plug: NGK LMAR8A - 9S
Battery: YTZ14S WET 12V-11.2Ah
Starting: Electric
Max Power: 66 kW / 88.5 hp @ 7500 rpm
Max Torque: 93 Nm / 68.5 lb-ft @ 5000 rpm
Clutch: Multi-plate wet clutch
Transmission: 6 Speed
Final Drive: #530 O-ring-sealed chain
Frame: Type Double steel cradle
Turning Radius: 2.7m
Front Suspension: 41mm fork with spring preload adjustability
Front Wheel Travel: 106 mm / 4.2 in
Rear Suspension: Twin shocks with spring preload adjustability
Rear Wheel Travel: 114.3 mm / 4.5 in
Front Brakes: 2x 296mm discs 4 piston calipers
Rear Brakes: Single 256mm disc
Wheels: Wire spoke
Front Tyre: 110/80R-18
Rear Tyre: 140/70R-18
Trail: 114 mm / 4.4 in
Caster: 27°
Dimensions: Length 2195 mm / 86.4 Width 835 mm / 32.8 in Height 1130 mm / 44.4 in
Wheelbase: 1490 mm / 58.7 in
Seat Height: 795 mm / 31.2 in
Ground Clearance: 135 mm / 5.3 in
Wet Weight: 245 kg / 540 lbs
Fuel Capacity: 17.5.Litres / 4.4 US gal
Reserve: 3.5 Litres
