Harley-Davidson Harley Davidson XLCH 1000 Sportster (1973-75) technical specifications
Harley-Davidson Harley Davidson XLCH 1000 Sportster is produced in 1973-75. Engine is Four stroke, 45° V-Twin, OHV, 2 valves per cylinder., displacement 997 cc / 60.8 cu-in , produces power 57 hp / 41.6 kW @ 6200 rpm and 60 lb ft / 81 Nm @ 3500 rpm. Harley-Davidson Harley Davidson XLCH 1000 Sportster weighs 235 kg / 518 lbs. Harley-Davidson Harley Davidson XLCH 1000 Sportster has 2 photos.
Technical specifications
+ Add to 'Compare list'| Model: | Harley Davidson XLCH 1000 Sportster |
| Years: | 1973-75 |
| Engine: | Four stroke, 45° V-Twin, OHV, 2 valves per cylinder. |
| Capacity: | 997 cc / 60.8 cu-in |
| Bore x Stroke: | 81 x 96.8 mm |
| Cooling System: | Air cooled |
| Compression Ratio: | 9.0:1 |
| Lubrication: | Dry sump |
| Induction: | 38mm Keihin carburetor |
| Ignition: | Electronic |
| Starting: | Kick & Electric optional |
| Max Power: | 57 hp / 41.6 kW @ 6200 rpm |
| Max Torque: | 60 lb ft / 81 Nm @ 3500 rpm |
| Clutch: | Wet, multiple discs, cable operated |
| Transmission: | 4 Speed |
| Final Drive: | Chain |
| Frame: | Steel, Double cradle frame |
| Front Suspension: | Telehydraulic forks |
| Rear Suspension: | Dual shocks swinging arm fork |
| Front Brakes: | Single 292mm disc |
| Rear Brakes: | Single 203mm drum |
| Front Tyre: | 3.75-19 |
| Rear Tyre: | 4.25-18 |
| Dry Weight: | 235 kg / 518 lbs |
| Fuel Capacity: | 9 Litres / 2.3 US gal |
